Accessory 24E2A

Connector TB1 Front - Limits 3

Pin# Symbol Function Description Notes

1 USER3 Input General Capture Flag Sinking or sourcing

2 PLIM3 Input Positive Limit Flag Sinking or sourcing

3 MLIM3 Input Negative Limit Flag Sinking or sourcing

4 HOME3 Input Home Flag Sinking or sourcing

5 FLG_3_RET Input Return for All Flags +V (12 to 24V) or 0V

Connector TB2 Front - Limits 4

Pin# Symbol Function Description Notes

1 USER4 Input General Capture Flag Sinking or sourcing

2 PLIM4 Input Positive Limit Flag Sinking or sourcing

3 MLIM4 Input Negative Limit Flag Sinking or sourcing

4 HOME4 Input Home Flag Sinking or sourcing

5 FLG_4_RET Input Return for All Flags +V (12 to 24V) or 0V

Acc-24E2 Option 1A Terminal Block Description 45
