Accessory 24E2A
Electrical Specifications
Description Specification Notes
ACC-24E2A Power
Requirements
5V @ 0.55A (±10%)
+15V @ 0.16A (±10%)
-15V @ 0.07A (±10%)
ACC-24E2A with Option 1A
Power Requirements
5V @ 0.95A (±10%)
+15V @ 0.30A (±10%)
-15V @ 0.12A (±10%)
Warning
If more than four ACC-24E2A’s with Option 1A are used in a UMAC system, the
ACC-E1 or ACC-F1 power supplies will not have enough 15V power. Delta Tau
recommends using an external ±15V power supply for systems with more than
four ACC-24E2A boards. The external power supply should be connected to the
unit from the terminal blocks (TB3 bottom) or DB connections (J1 or J2 Bottom)
and jumpers E85, E87, and E88 must also be removed.
EMC and Safety
Item Description
CE Mark
Full Compliance
EMC EN55011 Class A Group 1
EN61000-3-2 Class A
EN61000-3-3
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN61000-4-5
EN61000-4-6
EN61000-4-11
Safety EN 61010-1
Flammability Class UL 94V-0
4 Specifications
