Delta Tau 24E2A - Acc-24 E2 A Option 1 Board (Channels 3 and 4)

Accessory 24E2A
Acc-24E2A Option 1 Board (Channels 3 and 4)
Jumper Config. Description Default
E1A 1-2 No Jumper for TTL Level input for CHU3 flag
Jumper 1-2 for DIR3+ output in Stepper Mode
No jumper
E1B 1-2 No Jumper for TTL Level input for CHV3 flag
Jumper 1-2 for DIR3- output in Stepper Mode
No jumper
E1C 1-2 No Jumper for TTL Level input for CHW3 flag
Jumper 1-2 for PUL3+ output in Stepper Mode
No jumper
E1D 1-2 No Jumper for TTL Level input for CHT3 flag
Jumper 1-2 for PUL3- output in Stepper Mode
No jumper
E2A 1-2 No Jumper for TTL Level input for CHU4 flag
Jumper 1-2 for DIR4+ output in Stepper Mode
No jumper
E2B 1-2 No Jumper for TTL Level input for CHV4 flag
Jumper 1-2 for DIR4- output in Stepper Mode
No jumper
E2C 1-2 No Jumper for TTL Level input for CHW4 flag
Jumper 1-2 for PUL4+ output in Stepper Mode
No jumper
E2D 1-2 No Jumper for TTL Level input for CHT4 flag
Jumper 1-2 for PUL4- output in Stepper Mode
No jumper
E85 1-2 Jump 1-2 for Backplane Supplied +15V
No Jumper for External Supplied +15V
Jump 1-2
E87 1-2 Jump 1-2 for Backplane Supplied AGND
No Jumper for External Supplied AGND
Jump 1-2
E88 1-2 Jump 1-2 for Backplane Supplied -15V
No Jumper for External Supplied -15V
Jump 1-2
6 E-Point Jumper Settings
