Accessory 24E2A
E-POINT JUMPER SETTINGS
Acc-24E2A Base Board (Channels* 1 and 2)
Jumper Config. Description Default
E1A 1-2 No Jumper for TTL Level input for CHU1 flag
Jumper 1-2 for DIR1+ output in Stepper Mode
No jumper
E1B 1-2 No Jumper for TTL Level input for CHV1 flag
Jumper 1-2 for DIR1- output in Stepper Mode
No jumper
E1C 1-2 No Jumper for TTL Level input for CHW1 flag
Jumper 1-2 for PUL1+ output in Stepper Mode
No jumper
E1D 1-2 No Jumper for TTL Level input for CHT1 flag
Jumper 1-2 for PUL1- output in Stepper Mode
No jumper
E2A 1-2 No Jumper for TTL Level input for CHU2 flag
Jumper 1-2 for DIR2+ output in Stepper Mode
No jumper
E2B 1-2 No Jumper for TTL Level input for CHV2 flag
Jumper 1-2 for DIR2- output in Stepper Mode
No jumper
E2C 1-2 No Jumper for TTL Level input for CHW2 flag
Jumper 1-2 for PUL2+ output in Stepper Mode
No jumper
E2D 1-2 No Jumper for TTL Level input for CHT2 flag
Jumper 1-2 for PUL2- output in Stepper Mode
No jumper
E5 1-2-3 Jump 1-2 for Turbo 3U CPU and MACRO CPU
** Jump 2-3 for legacy MACRO CPU (before 6/00)
Jump 1-2
E13 1-2-3 Jump 1-2 to receive phase and servo clocks
Jump 2-3 to transmit phase and servo clocks
Factory set
E85 1-2 Jump 1-2 for Backplane Supplied +15V
No Jumper for External Supplied +15V
Jump 1-2
E87 1-2 Jump 1-2 for Backplane Supplied AGND
No Jumper for External Supplied AGND
Jump 1-2
E88 1-2 Jump 1-2 for Backplane Supplied -15V
No Jumper for External Supplied -15V
Jump 1-2
OPT1 1-2 For factory use only
OPT2 1-2 For factory use only
* The channels refer to the Servo IC associated with the Acc-24E2 base board. For example,
an eight-axis application would have two Acc-24E2s with option 1. The first Acc-24E2
would have axes 1-4 and the second Acc-24E2 would contain axes 5-8.
** For legacy MACRO Stations (part number 602804-100 thru 602804-104)
E-Point Jumper Settings 5
