Delta Tau 24E2A - DB15 Style Connector J1 Bottom Amp - out 1;Analog Power; DB15 Style Connector J2 Bottom Amp - out 2;Analog Power

Accessory 24E2A
DB15 Style Connector J1 Bottom Amp – Out 1/Analog Power
Pin# Symbol Function Description Notes
1 DAC1A+ Output Phase A Analog Out +/-10V, ref to AGND
2 DAC1B+ Output Phase B Analog Out +/-10V, ref to AGND
3 AE_NC_1 Output Amplifier Enable Normally closed
4 AE_NO_1 Output Amplifier Enable Normally open
5 AFAULT_1- Input
6 AA-15V Input* Analog Negative Supply Voltage Remove jumpers E85, E87, E88 if
using external power
7 AAGND Input* Analog Reference Voltage Remove jumpers E85, E87, E88 if
using external power
8 AA-15V Input* Analog Negative Supply Voltage Remove jumpers E85, E87, E88 if
using external power
9 DAC1A- Output Phase A Analog Out -/+10V; ref to AGND
10 DAC1B- Output Phase B Analog Out -/+10V; ref to AGND
11 AE_COM_1 Input Amplifier Enable
12 AFAULT_1+ Input
13 AA+15V Input* Analog Positive Supply Voltage Remove jumpers E85, E87, E88 if
using external power
14 AAGND Input* Analog Reference Voltage Remove jumpers E85, E87, E88 if
using external power
15 AA+15V Input* Analog Positive Supply Voltage Remove jumpers E85, E87, E88 if
using external power
*External power supply inputs for opto-isolation from the digital ground plane.
DB15 Style Connector J2 Bottom Amp – Out 2/Analog Power
Pin# Symbol Function Description Notes
1 DAC2A+ Output Phase A Analog Out +/-10V, ref to AGND
2 DAC2B+ Output Phase B Analog Out +/-10V, ref to AGND
3 AE_NC_2 Output Amplifier Enable Normally closed
4 AE_NO_2 Output Amplifier Enable Normally open
5 AFAULT_2- Input
6 AA-15V Input* Analog Negative Supply Voltage Remove jumpers E85, E87, E88 if
using external power
7 AAGND Input* Analog Reference Voltage Remove jumpers E85, E87, E88 if
using external power
8 AA-15V Input* Analog Negative Supply Voltage Remove jumpers E85, E87, E88 if
using external power
9 DAC2A- Output Phase A Analog Out -/+10V; ref to AGND
10 DAC2B- Output Phase B Analog Out -/+10V; ref to AGND
11 AE_COM_2 Input Amplifier Enable
12 AFAULT_2+ Input
13 AA+15V Input* Analog Positive Supply Voltage Remove jumpers E85, E87, E88 if
using external power
14 AAGND Input* Analog Reference Voltage Remove jumpers E85, E87, E88 if
using external power
15 AA+15V Input* Analog Positive Supply Voltage Remove jumpers E85, E87, E88 if
using external power
*External power supply inputs for opto-isolation from the digital ground plane.
48 Acc-24E2A DB15 Connector Option
