Chapter 3 Product Specifications
3-83
3_
Digital-to-analog
conversion
Voltage output
output voltages
which are averaged
is 100.)
Operating error (Full
temperature range)
(The number of
output voltages
which are averaged
is 100.)
±0.04%
Linearity error
(Room temperature)
±0.004%
Linearity error (Full
temperature range)
±0.004%
Hardware resolution
16 bits
Permissible load
impedance
1 kΩ~2 MΩ: ±10 V and 0 V~10 V
≧500 Ω: 1 V~5 V
Digital-to-analog
conversion
Current output
Rated output range
0 mA~20 mA
4 mA~20 mA
Hardware output
range
-0.2 mA~20.2 mA 3.8 mA~20.2 mA
Operating error
(Room temperature)
(The number of
output currents
which are averaged
is 100.)
±0.06%
Operating error (Full
temperature range)
(The number of
output currents
which are averaged
is 100.)
±0.07%
Linearity error
(Room temperature)
±0.01%
Linearity error (Full
temperature range)
±0.01%
Hardware resolution
16 bits
Permissible load
impedance
≦550 Ω
 AH06XA-5A
Electrical specifications
Module name
AH06XA-5A
