Delta AH Motion Series - Page 99

Chapter 3 Product Specifications
3-67
3_
Dimensions:
100
1 2
1 2
1 2
19 20
19 20
39 40
CN1
CN2
CN3
Dimensions are in cm.
- I/O extension cable: UC-ET010-24A (DVPACAB7A10)
1
1
1 2
1 2
39 4039 40
Number
Name
Description
1 40-pin IDC connector
Connecting a digital input/output module and the external terminal module
UB-10-OT32A(DVPAETB-OT32A)
