Delta VFD015EL43W-1 - Motor Disconnection Detection Time; Motor Disconnection Detection Current Level

Chapter 4 Parameters  VFD-EL-W
4-64
3 IGBT overheat (oH1)
4 Reserved
5 Overload (oL)
6 Overload (oL1)
7 Motor overload (oL2)
8 External Fault (E.F.)
9 Current exceeds two times the rated current during acceleration (ocA)
10 Current exceeds two times the rated current during deceleration (ocd)
11 Current exceeds two times the rated current during constant speed operation
(ocn)
12 Reserved
13 Reserved
14 Phase-loss (PHL)
15 Reserved
16 Auto-acceleration / auto-deceleration failure (CFA)
17 Software/password protection (codE)
18 Power Board CPU WRITE failure (cF1.0)
19 Power Board CPU READ failure (cF2.0)
20 CC, OC Hardware protection failure (HPF1)
21 OV Hardware protection failure (HPF2)
22 Reserved
23 OC Hardware protection failure (HPF4)
24 U-phase error (cF3.0)
25 V-phase error (cF3.1)
26 W-phase error (cF3.2)
27 DC bus error (cF3.3)
28 IGBT Overheat error (cF3.4)
29–31 Reserved
32 Reserved
33 Reserved
34 Motor PTC overheat protection (PtC1)
35 FBE_ERR: PID feedback error (Incorrect feedback signal)
36 dEv: unusual PID feedback deviation
37 OPHL
38–40 Reserved
 Pr.06.08 to Pr.06.12 store the five most recent faults that occurred. After clearing the cause of the faults, use
the RESET command to reset the drive.
06.13
Motor Disconnection Detection Time
Unit: 1
Settings 0.1–60.0 sec. Default: 0.0
0.0: Disable
06.14 Motor Disconnection Detection Current Level
Settings 10–100% Default: 30
 Use Pr.06.13 with Pr.06.14. When three-phase imbalance occurs among three-phase motors and the
imbalance reaches Pr.06.14 setting percentage (the percentage is 100% equal to the AC motor drive's rated
current settings in Pr.00.01), and lasts the time set in Pr.06.13, OPHL warning displays and the drive stops to
prevent the motor from damage due to the three-phase unbalanced operation.
