Chapter 4 Parameters
VFD-EL-W
4-27
4.3 Description of Parameter Settings
Group 0: User Parameters
You can set this parameter during operation.
00.00
AC Motor Drive Identity Code
Settings Read Only Default: ##
00.01
AC Motor Drive Rated Current Display
Settings Read Only Default: #.#
Pr. 00.00 displays the AC motor drive identity code. The identity code includes the capacity, rated current,
rated voltage and the maximum carrier frequency. The following table explains the identity code.
Pr.00.01 displays the rated current of the AC motor drive. You can use it to check if the AC motor drive is
correct.
230V Series
kW 0.2 0.4 0.75 1.5 2.2
HP 0.25 0.5 1.0 2.0 3.0
Pr.00.00 0 2 4 6 8
Rated Output Current (A) 1.6 2.5 4.2 7.5 11.0
Max. Carrier Frequency 12 kHz
460V Series
kW 0.4 0.75 1.5 2.2 4.0
HP 0.5 1.0 2.0 3.0 5.5
Pr.00.00 3 5 7 9 11
Rated Output Current (A) 1.5 2.5 4.2 5.5 9.0
Max. Carrier Frequency 12 kHz
00.02
Parameter Reset
Default: 0
Settings 0 Parameter can be read/written
1 All parameters are read-only
8 Keypad lock
9 Reset all parameters to defaults (50Hz, 230V/400V or 220V/380V depending on
Pr.00.12)
10 Reset all parameters to defaults (60Hz, 220V/440V)
9 or 10: Resets all parameters to defaults when the parameter settings are abnormal.
9: Resets all parameters to defaults for 50 Hz; the base voltage depends on the Pr.00.12 settings.
1: All parameters are read-only and you cannot change any parameter settings. Err displays when you enter
any input. To write all parameters, set Pr.00.02 = 0.
00.03
Start-up Display Selection
Default: 0
Settings 0 Display the frequency command value (F)
1 Display the actual output frequency (H)
2 Display the output current in Amps supplied to the motor (A)
3 Display the content of the user-defined unit (U)
4 FWD/REV command
Determines the start-up display page after power is applied to the drive.
