The contents of the available addresses are shown in the following table.
Content Address Function
AC motor drive
Parameters
GGnnH
GG means parameter group, nn means parameter number. For
example, the address of Pr.04.01 is 0401H. Refer to Chapter 4
Parameters for the function of each parameter. When reading
parameters by command code 03H, only one parameter can be read
at a time.
Command
Write only
2000H
bit 0–1
00B: No function
01B: Stop
10B: Run
11B: Jog + Run
bit 2–3
Reserved
bit 4–5
00B: No function
01B: FWD
10B: REV
11B: Change direction
bit 6–7
00B: Comm. forced first acceleration/deceleration
01B: Comm. forced second acceleration/deceleration
bit 8–15
Reserved
2001H Frequency command
2002H
bit 0 1: E.F. (external fault) ON
bit 1 1: Reset
bit 2 1: B.B. ON
bit 3–4
bit 6–15
Reserved
Fire mode
enabled
2002H Bit 5
00B: No function
01B: Fire mode enabled (Does not include the running
commands)
Status
monitor
Read only
2100H
Error code:
0: No error occurred
1: Over-current (oc)
2: Over-voltage (ov)
3: IGBT Overheat (oH1)
4: Reserved
5: Drive overload (oL)
6: Motor overload1 (oL1)
7: Over-torque (oL2)
8: External fault (EF)
9: Over-current during acceleration (ocA)
10: Over-current during deceleration (ocd)
11: Over-current during constant speed (ocn)
12: Reserved
13: Reserved
14: PHL (Phase-Loss)
15: Reserved
