Chapter 4 Parameters
VFD-EL-W
4-98

Related parameters when setting Pr.10.35=1
Parameter
Function  Settings  Default
End
user’s
master
End
user’s
slave
Note
00.03
Start-up
Display
Selection
0: Display the frequency command
value (F)
0  3  3

1: Display the actual output frequency
(H)

2: Display the output current in Amps
supplied to the motor (A)

3: Display the content of the user-
defined unit (U)

4: FWD/REV command
00.04
Content of
Multi-function
Display
0: Display the content of the user-
defined unit (U)
0  8  8
1: Display the counter value (c)
2: Display the status of multi-function
input terminals (d)
3: Display the DC bus voltage (u)
4: Display the output voltage (E)
5: Display the PID analog feedback
signal value in % (b)
6: Display the output power factor
angle (n)
7: Display the output power (P)
8: Display the setting values for PID
control and feedback signal
9: Display the AVI (I) (V)
10: Display the ACI (mA/V) (i)
11: Display the temperature of the
IGBT in °C (h)
00.13
User-defined
Value
(corresponds
to max.
operating
frequency
Pr.01.00)
0–9999  0  100  100
Sets the constant
pressure control
to correspond to
the largest
physical quantity
and the decimal
place. The
number displayed
is 10.0 currently.
00.14
Decimal Place
of User-
defined Value
0–3  0  1  1

Parameter
Function  Settings  Default
End
user’s
master
End
user’s
slave
Note
01.00
Maximum Output
Frequency (Fmax)
50.00–400.0 Hz  60.00
60.00
60.00
Follows the
specifications of
pumps
01.01
Motor Rated
Frequency (Fbase)
0.10–400.0 Hz  60.00
60.00
60.00
01.02
(Vbase)
230V series: 0.1–255.0 V  220.0
220.0
220.0
460V series: 0.1–510.0 V  440.0
