Chapter 4 Parameters  VFD-EL-W
4-2
4.1 Summary of Parameter Settings
: You can set this parameter during operation.
Group 0 User Parameters
Parameter Function Setting Default Customer
00.00
Identity Code of the AC motor
drive
0: 230V, 0.25HP
2: 230V, 0.5HP
3: 460V, 0.5HP
4: 230V, 1 HP
5: 460V, 1 HP
6: 230V, 2 HP
7: 460V, 2 HP
8: 230V, 3 HP
9: 460V, 3 HP
11: 460V, 5.5 HP
Read
only
00.01
Rated Current Display of the AC
motor drive
Read only
Read
only
00.02 Parameter Reset
0: Parameter can be read/written
0
1: All parameters are read only
8: Keypad lock
9: All parameters are reset to default
(50 Hz, 230V/400V or 220V/380V
depends on Pr.00.12)
10: All parameters are reset to default
(60 Hz, 220V/440V)
00.03 Start-up Display Selection
0: F (frequency command)
0
1: H (actual frequency)
2: A (output current)
3: U (user-defined, see Pr.00.04)
4: FWD/REV command
00.04 Content of Multi-function Display
0: Display the content of user-
defined unit
(Uxxx)
0
1: Display the counter value (c)
2: Display the status of multi-function in
put
terminals (d)
3: Display DC bus voltage (u)
4: Display output voltage (E)
5: Display PID analog feedback signal value
(b) (%)
6: Output power factor angle (n)
7: Display output power (P)
8: Display PID setting and feedback signal
9: Display AVI (I) (V)
10: Display ACI (i) (mA)
11: Display the temperature of IGBT (h) (°C)
00.05 User-Defined Coefficient K 0.1–160.0 1.0
