Chapter 4 Parameters
VFD-EL-W
4-16
Group 7 Motor Parameters
Parameter
Explanation Settings Default
Customer
07.00
Motor Rated Current 23–120% FLA 100
07.01
Motor No-Load Current 0–99% FLA 40
07.02
Torque Compensation 0.0–10.0 0.0
07.03
Slip Compensation Gain 0.00–10.00 0.00
07.04
Motor Parameter Auto-Tuning
0: Disable
1: Auto-tuning R1 (Motor does not run)
2: Auto-tuning R1 + No-load current
(with running motor)
0
07.05
Motor Line-to-line Resistance R1
(Motor 0)
0–65535 mΩ 0
07.06 Motor Rated Slip (Motor 0) 0.00–20.00 Hz 3.00
07.07 Slip Compensation Limit 0–250% 200
07.08
Torque Compensation Time
Constant
0.01–10.00 sec. 0.10
07.09
Slip
Compensation Time Constant
0.05–10.00 sec. 0.20
07.10
Accumulated Motor Operation
Time (Minute)
0–1439 Min. 0
07.11
Accumulated Motor Operation
Time (Day)
0–65535 Day 0
07.12 Motor PTC Overheat Protection
0: Disable
1: Enable
0
07.13
Motor PTC Protection Input
Response Time
0–9999 (*2 ms) 100
07.14
Motor PTC Overheat Protection
Level
0.1–10.0 V 2.4
07.15
Motor PTC Overheat Warning
Level
0.1–10.0 V 1.2
07.16
Motor PTC Overheat Reset Delta
Level
0.1–5.0 V 0.6
07.17 Motor PTC Overheat Action
0: Warn and ramp to stop
1: Warn and coast to stop
2: Warn and keep operating
0
