Chapter 4 Parameters  VFD-EL-W
4-8
Group 3 Output Function Parameters
Parameter Function Setting Default Customer
03.00
Multi-function Output
Relay (RA1, RB1,
RC1)
0: No function
1: Indication during RUN
2: Indication of master frequency reached
8
3: Zero speed
4: Over-torque detection
5: Base-Block (B.B.) indication
6: Low-voltage indication
7: Operation mode indication
8: Fault indication
9: Desired frequency reached
10: Terminal count value reached
11: Preliminary count value reached
12: Over-voltage stall prevention
13: Over-current Stall prevention
14: IGBT overheat warning
(85°C: ON, 80°C: OFF)
15: Over-voltage
16: PID feedback error
17: Forward command
18: Reverse command
19: Zero speed output signal
20: Warning
21: Mechanical brake control (Desired frequency
reached)
22: Drive ready
23: Multi-pump system error display (only master)
24: Preheating function indication
25: Fire mode indication
03.02
Desired Frequency
Reached
0.00–400.0 Hz 0.00
03.05 Terminal Count Value 0–9999 0
03.06
Preliminary Count
Value
0–9999 0
03.07
EF Active when
Terminal Count Value
Reached
0: Terminal count value reached, no EF display
0
1: Terminal count value reached, EF active
03.08 Fan Control
0: Fan is always ON
0
1: One minute after the AC motor drive stops, the fan
is OFF.
2: Fan is ON when the AC motor drive runs, fan is
OFF when the AC motor drive stops.
3: Fan is ON when the preliminary heat sink
temperature is reached.
4: Fan is ON when the AC motor drive runs; fan is
OFF when the AC motor drive stops. And the fan
is in a standby mode at 0 Hz.
