DEMA CPM 310 G User Manual

- 4 -
5.6.8. I
2
>> Negative Sequence Overcurrent 2
nd
Threshold Protection Menu p.74
5.6.9. %(I
2
/I
1
)> Broken Conductor Protection Menu p.75
5.6.10. I< Phase Undercurrent Protection Menu p.76
5.6.11. I
Θ
> Thermal Overload Protection Menu p.77
5.6.12. Auto-recloser Settings Menu p.80
5.7. Main Menu p.83
5.7.1. Measurement Menu p.85
5.7.1.1. RMS Current and Frequency Measurements Menu p.86
5.7.1.2. Max RMS Current Measurements Menu p.87
5.7.1.3. Fundamental Harmonics Measurements Menu p.88
5.7.1.4. Positive and Negative Sequence Current Measurements Menu p.89
5.7.1.5. Thermal Θ Measurements Menu p.90
5.7.1.6. Input & Output Status Monitoring Menu p.91
5.7.1.7. Circuit Breaker Measurements p.92
5.7.1.8. Auto-recloser (ARCL) Measurements Menu p.93
5.7.1.9. LED Status Menu p.94
5.7.2. Communication Settings Menu p.95
5.7.3. Event Records Menu p.96
5.7.4. System Settings Menu p.97
5.7.5. Current Transformer Settings Menu p.100
5.7.6. Automatic Control Settings Menu p.102
5.7.6.1. Cold Load Pickup Settings Menu p.103
5.7.6.2. Output Relay Settings Menu p.105
5.7.6.3. Trip Settings Menu p.106
5.7.6.4. Input Settings Menu p.107
5.7.6.5. Blocking Logic Selectivity Settings Menu p.108
5.7.6.6. Circuit Breaker Failure Recognition Settings Menu p.111
5.7.6.7. Auxiliary Timer Settings Menu p.113
5.7.6.8. Delaying Logic Selectivity Settings Menu p.114
5.7.6.9. Auto-recloser (ARCL) Settings Menu p.115
5.7.6.10. CB Supervision Settings Menu p.118
5.7.6.11. Programmable LEDs Settings Menu p.121
5.7.6.12. Latching Settings Menu p.123
5.7.6.13. Alarm Settings Menu p.125
5.7.7. Function Test Menu p.126
5.7.8. Fault Records Menu p.127
6. DigiConnect PC Program Manual p.128
6.1. Operating System & Hardware Requirements p.129
6.2. Program Setup p.130
6.3. Program Startup p.133
6.4. Software Introduction and Guide p.136
6.4.1. Welcome Screen p.137
6.4.2. Measurements p.138
6.4.2.1. Analog Values p.138
6.4.2.1.1. RMS Current p.138
6.4.2.1.2. Fundamental Harmonics p.139
6.4.2.1.3. P/N Sequences p.140
6.4.2.1.4. Max. RMS Current p.141
6.4.2.2. Circuit Breaker Measurements p.142
6.4.2.3. ARCL Measurements p.143
6.4.2.4. Remote Control p.144
6.4.3. Alarms / Event Records Menu p.145
6.4.3.1. Alarms p.145
6.4.3.2. Event Records p.146
6.4.3.3. Trip Records p.147
6.4.4. Settings Menu p.148
