Denon AVR-1612 Service Manual

103
Ref. No. Part No. Part Name Remarks Q'ty New
C4066 00D9430175108 ELECT CAP 10UF 50V
CCEA1HH100T
C4067, 4068 00D9630324607 CAP , ELECT(10V/47uF) E3 CCEA1AH470T
C4067, 4068 943134500080S ELECT CAP 47UF 63V E2,EA,E1C CCEA1JH470TS *
C4069 nsp CHIP CAP 220PF 50V
CCUS1H221JA
C4071 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C4073 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C4079 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C4080,4081 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C4083 00D9430062101 ELECT CAP 100UF 16V E3 CCEA1CH101T
C4083 943134500060S ELECT CAP 100UF 50V E2,EA,E1C CCEA1HH101T *
C4084 00D9630324607 CAP , ELECT(10V/47uF)
CCEA1AH470T
C4085 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C4086 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4087 00D9630324607 CAP , ELECT(10V/47uF) CCEA1AH470T
C4088 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4090-4094 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4097,4098 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4103 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4105 00D9430148708 ELECT CAP 47UF 50V CCEA1HH470T
C4106 00D9430103808 ELECT CAP 470UF 10V CCEA1AH471T
C4114 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C4115-4125 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C4126-4134 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
OTHERS PARTS GROUP
BD401 nsp CHIP FERRITE BEAD(60ohm 1608)
CLZ9R005Z
BK401 nsp PCB BRACKET CMD1A569
CN401 nsp PIN SOCKET (19P,1.25mm,ANGLE, B-TO-B) CJP19HJ282Z
CN404 nsp PIN SOCKET (23P,1.25mm,ANGLE, B-TO-B) CJP23HJ282Z
CN405 nsp PIN SOCKET (13P,1.25mm,ANGLE, B-TO-B) CJP13HJ282Z
CN406 nsp
WIRE ASS'Y Locking (YH)
(9P,2.5MM,220MM,#24,105)
CWB4C0092203D
CN407 nsp LOCKINGTYPE STRAIGHTWAFER 2MM CJP03GI236ZW
CN408 nsp LOCK-WAFER/STRAIGHT/2mm CJP13GI236ZW
ET41 nsp EARTH PALTE HJT1A025
JK401 943643010150S JACK NOSPCC2PW/R CJJ4N034U
JK402 943643010190S JACK NOSPCCRCA/SVIDEO CJJ9N004U
JK403 943643010160S JACK NOSPCC1PBLACK CJJ4M046U
JK404 943643010170S JACK NOSPCC6PWWW/RRR CJJ4R019T
JK405 943643010180S JACK NOSPCC2PY/Y CJJ4N092U
L401 nsp COIL , AXAIL (10UH) HLQ02C100KT
L4001,4002 943115010270S MPX COIL(FM19KHzFILTER) CLM4B001Z
TU401 943183010320S TUNER(USA)FM(SCREW:FTYPE),AM(S/LAB) E3 CNVMW004MV1S63SN
TU401
943183010310S
TUNER(EUR)FM,AM,RDS(S/LAB) E2,EA,E1C CNVMW104MV1S63N

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
