Denon AVR-1612 Service Manual

94
PARTS LIST OF P.C.B. UNIT
z
Parts indicated by "nsp" on this table cannot be supplied.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model(AVR-1612) EA : Australia model 1622E1C : China model(AVR-1622)
BK : Black model SP : Premium Silver model
FRONT PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC601,602 943239005300M
IC BA4560RF HVIBA4560RF
Q6001 943219006820S TR KTC1027Y CVTKTC1027YT
Q6002 943216500020S TR RT1N141C CVTRT1N141C
Q6003,6004 943214500020S TR 2SC3052 CVT2SC3052
Q6005 00MHT600141B1 TR KTA1271Y HVTKTA1271YT
Q6006 943216500020S TR RT1N141C CVTRT1N141C
Q6007 943215500020S TR RT1P141C CVTRT1P141C
Q6009 943215500020S TR RT1P141C CVTRT1P141C
Q6010 943216500020S TR RT1N141C CVTRT1N141C
Q6011 943215500020S TR RT1P141C CVTRT1P141C
Q6012 943216500020S TR RT1N141C CVTRT1N141C
D6001,6002 943203003150S DIODE 1N4007T HVD1N4007T
D6003 90M-HD302360R DIODE ZJ6.8BT CVDZJ6.8BT
D6004 00D9430087209 ZENER DIODE ZJ24B 1/2W CVDZJ24BT
D6005 90M-HD302450R ZENER DIODE ZJ13B 1/2W CVDZJ13BT
D6008 963209003510S DIODE , RELIABLE ESD PROTECTION CVDCDS3C05HDMI1
D6011-6013 963209003510S DIODE , RELIABLE ESD PROTECTION CVDCDS3C05HDMI1
D6014 943176010090S LED BLBJEGJ204L CVDBLBJEGJ204L
D6017-6020 943209001080S DIODE 1SS355T CVD1SS355T
D6027,6028 943209001080S DIODE 1SS355T CVD1SS355T
D6412 943202010080S DIODE ZJ5.1B CVDZJ5.1BT
D6429,6430 943202010080S DIODE ZJ5.1B CVDZJ5.1BT
D6451,6452 943209001080S DIODE 1SS355T CVD1SS355T
RESISTORS GROUP
z
R6008 943124500040S
RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R6090,6091 nsp RES,M-OXIDEFILM(2W/470ohm) CRG2SANJ471RT
CAPACITORS GROUP
C6002 nsp
MYLAR CAP 0.1UF 50V J HCQI1H104JZT
C6003 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C6004 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C6005 00MOA22706320 ELECT CAP 220UF 63V CCEA1JH221E
C6006 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C6007 nsp METALLIZEDFILM CAP 0.047UF 100V CCME2A473JXT
C6009 nsp CHIP CAP 0.1UF/50V/2012 CCUC1H104KC
C6010 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C6011 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6013-6015 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C6016 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C6017 nsp METALLIZEDFILM CAP 0.047UF 100V CCME2A473JXT
C6019 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C6020 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C6035 943134010670S ELECT CAP 47UF 16V CCEA1CKS470T
C6036 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C6039 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C6053,6054 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C6055 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6057 00D9430173003 CAP , ELECT(10V/220uF)-S CCEA1AKS221T
C6058-6060 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
