Denon AVR-1612 Service Manual

93
Ref. No. Part No. Part Name Remarks Q'ty New
5 - INSTRUCTION MANUAL ASS'Y - 1
5-1 nsp BATTERY(AA ) CABR6PPB 2
5-2 352010017003D INST. MANUAL(E3 CD-ROM) E3 CFT1A032Z 1 *
5-2 352010018006D INST. MANUAL(E2 CD-ROM) E2,EA CFT1A033Z 1 *
5-2 352010030006D INST. MANUAL(1612E1C CD-ROM) E1C CFT1A035Z 1 *
5-2 352010031009D INST. MANUAL(1622E1C CD-ROM) 1622E1C CFT1A036Z 1 *
5-3 nsp POLY BAG(MANUAL) CPB1A197Z 1
★
5-4 nsp BARCODE LABEL(MANUAL) CQB1A971 1
5-5 nsp S.S LIST CQE1A226P 1
5-6 nsp
WARRANTY CARD E3 CQE1A224R 1
5-7 nsp
CARD FOR CHINA INDENTIFICATION E1C,1622E1C CQE1A450Z 1
5-8 nsp
WARRANTYCARD CHINA E1C,1622E1C CQE1A473Z 1
5-9 542110053009D QUICK MANUAL(E3) E3 CQX1A1615Z 1 *
5-9 542110054002D QUICK MANUAL(E2) E2,EA CQX1A1616Z 1 *
5-9 542110058004D QUICK MANUAL(E1C) E1C CQX1A1618Z 1 *
5-9 542110059007D QUICK MANUAL(1622E1C) 1622E1C CQX1A1619Z 1 *
5-10 90M-ZA000230R FM 1 POLANT(UL) E3 CSA1A019Z 1
5-10 00D9430113403 FM 1 POLE ANT.
E2,EA,E1C,1622E1C CSA1A018Z 1
5-11 943116009500S AM LOOP ANT CSA1A032Z 1
6 307010088005D REMOCON ASS'Y(RC-1157) CARTAVR1612 1 *
7 943531012590D OUTCARTON BOX E3,BKE1C CPG1A942W
1 *
7 943531012600D OUTCARTON BOX E2,EA CPG1A942V 1 *
7 943531100060D OUTCARTON BOX SPE1C CPG1A942U 1 *
7 943531012610D OUTCARTON BOX 1622E1C CPG1A942S 1 *
8 nsp CONTROL LABEL CQB1A993Z 1
9 nsp COLOR LABEL(WHITE) SP CQB1A676 2
10 324010001003D DM-A409EM CJXAVR1612A 1

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
