Denon AVR-1612 - Input Pcb Assy

11
3. INPUT PCB ASSY
(1) Disconnect the connector wires and remove the INPUT PCB ASSY.
(2) Remove the screws.
Proceeding :
TOP CABINET
HDMI UNIT ASSY
→
INPUT PCB ASSY
→
INPUT PCB ASS'Y
cut
CN407CN408
CN931
Shooting of photograph: A
