Denon AVR-1612 Service Manual

89
PARTS LIST OF EXPLODED VIEW
z
Parts indicated by "nsp" on this table cannot be supplied.
z
P.W.B. ASS'Y indicated by "nsp" on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts list and order replacement parts.
z
Parts indicated by the "
★
" mark are not illustrated in the exploded view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model(AVR-1612) EA : Australia model 1622E1C : China model(AVR-1622)
BK : Black model SP : Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
1 nsp FRONT PCB ASS'Y E3
COP12381B 1 *
1 nsp FRONT PCB ASS'Y E2,EA
COP12381C 1 *
1 nsp FRONT PCB ASS'Y E1C,1622E1C
COP12381E 1 *
C1 - HEADPHONE PCB
-
C2 - USB PCB -
C3 - FRONT PCB -
C4 - VOLUME PCB -
C7 - WIRE SUPPORT PCB -
2 nsp POWER PCB ASS'Y E3 COP12380B 1 *
2 nsp POWER PCB ASS'Y E2,EA
COP12380C 1 *
2 nsp POWER PCB ASS'Y E1C,1622E1C
COP12380E 1 *
C5 - SMPS PCB
-
C6 - REGULATOR PCB -
C13 - CONNECTOR PCB -
z
C9 943101012320D
TRANS , POWER AVR1612/E3 , (85.8X63) E3 CLT5U048ZU 1 *
z
C9 943101012330D
TRANS , POWER AVR1612/E2 , (85.8X63) E2,EA CLT5U048ZE 1 *
z
C9 943101012340D
TRANS , POWER AVR1612/E1C , (85.8X63) E1C,1622E1C CLT5U048ZH 1 *
3 nsp MAIN PCB ASS'Y E3
COP12379B 1 *
3 nsp MAIN PCB ASS'Y E2,EA
COP12379C 1 *
3 nsp MAIN PCB ASS'Y E1C,1622E1C
COP12379E 1 *
C8 - WIRE SUPPORT PCB
-
C10 - MAIN PCB -
C17 - GND CONNECT PCB -
C11 nsp INPUT PCB ASS'Y E3 COP12378B 1 *
C11 nsp INPUT PCB ASS'Y E2,EA
COP12378C 1 *
C11 nsp INPUT PCB ASS'Y E1C,1622E1C
COP12378E 1 *
C12 8U6331007200D DIGITAL PCB ASS'Y E3
COP12377B 1 *
C12 8U6331007300D DIGITAL PCB ASS'Y E2,EA
COP12377C 1 *
C12 8U6331007400D DIGITAL PCB ASS'Y E1C
COP12377E 1 *
C12 8U6331011000S DIGITAL PCB ASS'Y 1622E1C
COP12377F 1 *
z
C14 90M-YC000780R CORD , POWER E3
CJA523FBYA 1
z
C14 90M-YC000850R CORD , POWER E1C,1622E1C
CJA2N047ZA 1
M1 00D9630362109 DENON BADGE(BLACK049) BK
CGB1A140U 1
M1 00D9630362202 DENON BADGE(SILVER 052) SP
CGB1A140T 1
M2 nsp EARTH , USB
CMC1A420 1 *
M3 nsp EARTH AUX
CMC1A421 1 *
M4 nsp BOTTOM CHASSIS
CUA1A328 1

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
