Denon AVR-1612 Service Manual

90
Ref. No. Part No. Part Name Remarks Q'ty New
M5 nsp SMPS BRACKET
CMD1A790 1 *
M6 943401100020D TOP CABINET(EMC) BK
CKC2A155ZK117 1 *
M6 943401100030D TOP CABINET(EMC) SP
CKC2A155ZD11 1 *
M7 nsp HEAT SINK
CMY1A371 1 *
M8 nsp PCB BRACKET
CMD1A417 2
M9 nsp BRACKET , MULTI AV8003
CMD1A665 1
M10 nsp BRACKET , PCB
CMD1A789 2 *
M11 nsp PANEL , REAR E2,EA
CKF3A447Z 1 *
M11 nsp PANEL , REAR E3
CKF1A447Z 1 *
M11 nsp PANEL , REAR E1C
CKF2A447Z 1 *
M11 nsp PANEL , REAR 1622E1C
CKF2A447Y 1 *
P1 943416012530D WINDOW FL
CGU1A459Z 1
P2 943412009840D VOLUME KNOB BK
CBN1A249 1
P2 943412009850D VOLUME KNOB SP
CBN1A249C73 1
P3 943419100020D RCA COVER BK
CGR1A510B28 1
P3 943419100030D RCA COVER SP
CGR1A510G45 1
P4 943402012360D PANEL , FRONT E2,EA
CGW1A509RHYB28 1 *
P4 943402012370D PANEL , FRONT E3
CGW1A509RHZB28 1 *
P4 943402012380D PANEL , FRONT SPE1C
CGW1A509RGXG45 1 *
P4 943402012390D PANEL, FRONT 1622E1C
CGW1A509RGVG45 1 *
P4
943402100190D PANEL, FRONT BKE1C CGW1A509RHUB28 1 *
P5 00D9630137807 STANDBY LENS
CGL1A289 1
P6 943411009860D BUTTON STANDBY ASS'Y BK
CBT1A1141ZA 1
P6 943411009870D BUTTON STANDBY ASS'Y SP
CBT1A1141YA 1
P7 943411012490D BUTTON , 4KEY BK
CBT1A1154B28 1
P7 943411012500D BUTTON , 4KEY SP
CBT1A1154G45 1
P8 943411012570D BUTTON , 5KEY BK
CBT1A1153XB28 1 *
P8 943411012580D BUTTON , 5KEY SP
CBT1A1153WG45 1 *
P9 00D9630365002 WIN 3KEY BUTTON BK
CBT1A1140B28 2
P9 00D9630365301 WIN 3KEY BUTTON SP
CBT1A1140G45 2
P10 943411012510D BUTTON , 3KEY BK
CBT1A1155ZB28 1
P10 943411012520D BUTTON , 3KEY SP
CBT1A1155YG45 1
P11 943407100020D FOOT
CKL1A190 4
P12 00D9430202902 FOOT CUSHION
CHG2A289 4
P13 nsp RUBBER
CHG1A113 6
P14 nsp INSULATOR , SILICON
CMX1A298 1
P15 nsp HOLDER,PCB
CHE2A030 6
P16 nsp BUSHING , AC CORD
E3,E1C,1622E1C CHR1A028 1
P17 943419100250D CGX1A492Z SHEET TOP AVR1612BK BK
CGX1A492Z 1 *
P17 943419100260D CGX1A492Y SHEET TOP AVR1612SP SP
CGX1A492Y 1 *
P18 45451000500AM STOPPER TOP BL PM6004 BK
CMH1A306Z 4
P18 45451000501AM STOPPER TOP SG PM6004 SP
CMH1A306Y 4
SCREWS
S1 nsp SCREW BK
CTB3+8JFZR 5
S1 nsp SCREW SP
CTB3+8JFN 5
S2 nsp SCREW
CTW3+8JR 2
S2 nsp SCREW
CTW3+8JR 12
S3 nsp SCREW
CTB3+10JR 22
S4 nsp SCREW
CTB3+6JR 2
S5 nsp SCREW , SPECIAL
CHD1A012ZR 15

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
