Denon AVR-1612 Service Manual

60
NO
NO
NO
NO
Is there damage in IC901
(TOP258MG)?
Is there the damage in D9001/D9002/
D9003/D9004?
Repair the solder short part of the PWB
board.
Check the damage of each part.
Repair the jumper wire.
Replace the damaged parts.
Replace the parts of damage.
Is the fuse (F9001) blown?
Is there solder short circuit in the PWB
board?
Is there a damaged part?
Does the jumper wire(D9012)
connected to the PWB have
disconnection?
Replace the IC901(TOP258MG) and
D9001/D9002/D9003/D9004.
DC 5V is not output.
YES
YES
YES
YES
YES
YES
YES
6. SMPS

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
