Denon AVR-1612 Service Manual

104
MAIN PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
Q7101,7102 00D2710301903 TR KTA1268BLATP
CVTKTA1268BLATPA
Q7103 00MHT800931A0 TR KTC3200GR HVTKTC3200GRT
Q7104 90M-HT800120R TR KTC3114A HVTKTC3114A
Q7105 90M-HT400490R POWER TR 2SD2390 HVT2SD2390
Q7106 90M-HT200440R POWER TR HVT2SB1560 HVT2SB1560
Q7107 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401
*
Q7108 943214500040S High Voltage NPN Transistors(SOT-23)
CVTMMBT5551
*
Q7201,7202 00D2710301903 TR KTA1268BLATP
CVTKTA1268BLATPA
Q7203 00MHT800931A0 TR KTC3200GR HVTKTC3200GRT
Q7204 90M-HT800120R TR KTC3114A HVTKTC3114A
Q7205 90M-HT400490R POWER TR 2SD2390 HVT2SD2390
Q7206 90M-HT200440R POWER TR HVT2SB1560 HVT2SB1560
Q7207 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401 *
Q7208 943214500040S High Voltage NPN Transistors(SOT-23)
CVTMMBT5551 *
Q7301,7302 00D2710301903 TR KTA1268BLATP
CVTKTA1268BLATPA
Q7303 00MHT800931A0 TR KTC3200GR HVTKTC3200GRT
Q7304 90M-HT800120R TR KTC3114A HVTKTC3114A
Q7305 90M-HT400490R POWER TR 2SD2390 HVT2SD2390
Q7306 90M-HT200440R POWER TR HVT2SB1560 HVT2SB1560
Q7307 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401 *
Q7308 943214500040S High Voltage NPN Transistors(SOT-23)
CVTMMBT5551 *
Q7401,7402 00D2710301903 TR KTA1268BLATP
CVTKTA1268BLATPA
Q7403 00MHT800931A0 TR KTC3200GR HVTKTC3200GRT
Q7404 90M-HT800120R TR KTC3114A HVTKTC3114A
Q7405 90M-HT400490R POWER TR 2SD2390 HVT2SD2390
Q7406 90M-HT200440R POWER TR HVT2SB1560 HVT2SB1560
Q7407 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401 *
Q7408 943214500040S High Voltage NPN Transistors(SOT-23)
CVTMMBT5551 *
Q7501,7502 00D2710301903 TR KTA1268BLATP
CVTKTA1268BLATPA
Q7503 00MHT800931A0 TR KTC3200GR HVTKTC3200GRT
Q7504 90M-HT800120R TR KTC3114A HVTKTC3114A
Q7505 90M-HT400490R POWER TR 2SD2390 HVT2SD2390
Q7506 90M-HT200440R POWER TR HVT2SB1560 HVT2SB1560
Q7507 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401 *
Q7508 943214500040S High Voltage NPN Transistors(SOT-23)
CVTMMBT5551 *
Q7601-7604 943216500030S TR KRC105M
CVTKRC105MT
Q7701 943212500020S High Voltage PNP Transistors(SOT-23) CVTMMBT5401 *
Q7702 00D2710301903 TR KTA1268BLATP
CVTKTA1268BLATPA
Q7703 00MHT800931A0 TR KTC3200GR HVTKTC3200GRT
Q7704 00D9430006206 T.R KTA1268GR HVTKTA1268GRT
Q7705,7706 00MHT800931A0 TR KTC3200GR HVTKTC3200GRT
Q7707 00D9430006206 TR KTA1268GR HVTKTA1268GRT
Q7708 00MHT800931A0 TR KTC3200GR HVTKTC3200GRT
D7102 90M-HD302390R DIODE ZJ3.3B CVDZJ3.3BT
D7103 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7104 90M-HD302390R DIODE ZJ3.3B CVDZJ3.3BT
D7105,7106 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7202 90M-HD302390R DIODE ZJ3.3B CVDZJ3.3BT
D7203 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7204 90M-HD302390R DIODE ZJ3.3B CVDZJ3.3BT
D7205,7206 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7302 90M-HD302390R DIODE ZJ3.3B CVDZJ3.3BT
D7303 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7304 90M-HD302390R DIODE ZJ3.3B CVDZJ3.3BT
D7305,7306 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7402 90M-HD302390R DIODE ZJ3.3B CVDZJ3.3BT
D7403 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7404 90M-HD302390R DIODE ZJ3.3B CVDZJ3.3BT
D7405,7406 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7502 90M-HD302390R DIODE ZJ3.3B CVDZJ3.3BT
D7503 00D9430182609 DIODE 1SS133MT CVD1SS133MT
D7504 90M-HD302390R DIODE ZJ3.3B CVDZJ3.3BT
D7505,7506 00D9430182609 DIODE 1SS133MT CVD1SS133MT

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
