Denon AVR-1612 Service Manual

105
Ref. No. Part No. Part Name Remarks Q'ty New
D7601-7604 00D9430182609 DIODE 1SS133MT
CVD1SS133MT
D7701 943203002640S DIODE , BRIDGE(8A/600V) HVDGBJ806
D7703 90M-HD302360R DIODE ZJ6.8BT CVDZJ6.8BT
D7704 00D9430182609 DIODE 1SS133MT CVD1SS133MT
CAPACITORS GROUP
C7101 00D9430175108 ELECT CAP 10UF 50V E3
CCEA1HH100T
C7101 943134500070S ELECT CAP 10UF 100V E2,EA,E1C CCEA2AH100TS *
C7102 nsp CERAMIC CAP 470PF 50V KB
CCKT1H471KB
C7103 nsp CERAMIC CAP 82PF 50V J CCCT1H820JC
C7104 nsp MYLAR CAP 2200PF 100V J HCQI1H222JZT
C7105 00MOA10705020 ELECT CAP 100UF 50V CCEA1HH101T
C7106 nsp CERAMIC CAP 33PF 50V J CCCT1H330JC
C7107 00D9430175108 ELECT CAP 10UF 50V E3 CCEA1HH100T
C7107 943134500070S ELECT CAP 10UF 100V E2,EA,E1C CCEA2AH100TS *
C7108 00D9430148708 ELECT CAP 47UF 50V
CCEA1HH470T
C7109 nsp SEMICONDUCTOR CAP 0.1UF 50V ZF CCFT1H104ZF
C7201 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C7202 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C7203 nsp CERAMIC CAP 82PF 50V J CCCT1H820JC
C7204 nsp MYLAR CAP 2200PF 100V J HCQI1H222JZT
C7205 00MOA10705020 ELECT CAP 100UF 50V CCEA1HH101T
C7206 nsp CERAMIC CAP 33PF 50V J CCCT1H330JC
C7207 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C7208 00D9430148708 ELECT CAP 47UF 50V CCEA1HH470T
C7209 nsp SEMICONDUCTOR CAP 0.1UF 50V ZF CCFT1H104ZF
C7301 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C7302 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C7303 nsp CERAMIC CAP 82PF 50V J CCCT1H820JC
C7304 nsp MYLAR CAP 2200PF 100V J HCQI1H222JZT
C7305 00MOA10705020 ELECT CAP 100UF 50V CCEA1HH101T
C7306 nsp CERAMIC CAP 33PF 50V J CCCT1H330JC
C7307 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C7308 00D9430148708 ELECT CAP 47UF 50V CCEA1HH470T
C7309 nsp SEMICONDUCTOR CAP 0.1UF 50V ZF CCFT1H104ZF
C7401 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C7402 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C7403 nsp CERAMIC CAP 82PF 50V J CCCT1H820JC
C7404 nsp MYLAR CAP 2200PF 100V J HCQI1H222JZT
C7405 00MOA10705020 ELECT CAP 100UF 50V CCEA1HH101T
C7406 nsp CERAMIC CAP 33PF 50V J CCCT1H330JC
C7407 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C7408 00D9430148708 ELECT CAP 47UF 50V CCEA1HH470T
C7409 nsp SEMICONDUCTOR CAP 0.1UF 50V ZF CCFT1H104ZF
C7501 00D9430175108 ELECT CAP 10UF 50V E3 CCEA1HH100T
C7501 943134500070S ELECT CAP 10UF 100V E2,EA,E1C CCEA2AH100TS *
C7502 nsp CERAMIC CAP 470PF 50V KB
CCKT1H471KB
C7503 nsp CERAMIC CAP 82PF 50V J CCCT1H820JC
C7504 nsp MYLAR CAP 2200PF 100V J HCQI1H222JZT
C7505 00MOA10705020 ELECT CAP 100UF 50V CCEA1HH101T
C7506 nsp CERAMIC CAP 33PF 50V J CCCT1H330JC
C7507 00D9430175108 ELECT CAP 10UF 50V E3 CCEA1HH100T
C7507 943134500070S ELECT CAP 10UF 100V E2,EA,E1C CCEA2AH100TS *
C7508 00D9430148708 ELECT CAP 47UF 50V
CCEA1HH470T
C7509 nsp SEMICONDUCTOR CAP 0.1UF 50V ZF CCFT1H104ZF
C7605,7606 nsp FILM CAP 0.015UF 100V J MYLAR HCQI1H153JZT
C7607,7608 nsp MYLAR CAP 0.047UF 50V HCQI1H473JZT
C7609-7611 nsp FILM CAP 0.015UF 100V J MYLAR HCQI1H153JZT
C7612-7614 nsp MYLAR CAP 0.047UF 50V HCQI1H473JZT
C7701 nsp CERAMIC CAP 0.01UF 50V ZF CCFT1H103ZF
C7702,7703 nsp METALLIZED CAP 0.1UF 250V J KCME2E104JP04T
C7704 943134010460S ELECT CAP 6800UF 63V (30X35) CCET63VKL5682NKZ
C7706 943134010460S ELECT CAP 6800UF 63V (30X35) CCET63VKL5682NKZ
C7707 943134010470S ELECT CAP 0.1UF 50V CCEA1HH0R1T
C7708 943134010480S ELECT CAP 100UF 100V CCEA2AH101E
C7710 nsp SEMICONDUCTOR CAP 0.1UF 50V ZF CCFT1H104ZF

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
