Denon AVR-1612 Service Manual

106
Ref. No. Part No. Part Name Remarks Q'ty New
C7711 943134010660S ELECT CAP 470UF 6.3V
CCEA0JH471T
C7712 nsp SEMICONDUCTOR CAP 0.1UF 50V ZF CCFT1H104ZF
C7713 943134010660S ELECT CAP 470UF 6.3V CCEA0JH471T
C7716 nsp ELECT CAP 47UF 16V CCEA1CH470T
C7717 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C7718-7722 nsp MYLAR CAP 0.047UF 50V HCQI1H473JZT
C7723 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
RESISTORS GROUP
R7106 nsp METAL OXID EFILM RES(1.2KOHM 1W)
CRG1SANJ122RT
R7110 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT
R7115,7116 nsp METAL OXID EFILM RES(1W/5.6Kohm) CRG1SANJ562RT
R7117,7118 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) FLAMERETARDANT CRG1SANJ4R7RT
R7119-7122 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) FLAMERETARDANT CRG2SANJR47RT
z
R7126 252310006520S PTC THEMISTORS, CHIP(95'C) CRTPRF18BD471QB5RB
R7132 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R7206 nsp METAL OXID EFILM RES(1.2KOHM 1W) CRG1SANJ122RT
R7210 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT
R7215,7216 nsp METAL OXID EFILM RES(1W/5.6Kohm) CRG1SANJ562RT
R7217,7218 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) FLAMERETARDANT CRG1SANJ4R7RT
R7219-7222 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) FLAMERETARDANT CRG2SANJR47RT
z
R7226 252310006520S PTC THEMISTORS, CHIP(95'C) CRTPRF18BD471QB5RB
R7232 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R7306 nsp METAL OXID EFILM RES(1.2KOHM 1W) CRG1SANJ122RT
R7310 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT
R7315,7316 nsp METAL OXID EFILM RES(1W/5.6Kohm) CRG1SANJ562RT
R7317,7318 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) FLAMERETARDANT CRG1SANJ4R7RT
R7319-7322 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) FLAMERETARDANT CRG2SANJR47RT
z
R7326 252310006520S PTC THEMISTORS, CHIP(95'C)
CRTPRF18BD471QB5RB
R7332 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R7406 nsp METAL OXID EFILM RES(1.2KOHM 1W) CRG1SANJ122RT
R7415,7416 nsp METAL OXID EFILM RES(1W/5.6Kohm) CRG1SANJ562RT
R7417,7418 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) FLAMERETARDANT CRG1SANJ4R7RT
R7419-7422 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) FLAMERETARDANT CRG2SANJR47RT
z
R7426 252310006520S PTC THEMISTORS, CHIP(95'C) CRTPRF18BD471QB5RB
R7432 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R7506 nsp METAL OXID EFILM RES(1.2KOHM 1W) CRG1SANJ122RT
R7510 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT
R7515,7516 nsp METAL OXID EFILM RES(1W/5.6Kohm) CRG1SANJ562RT
R7517,7518 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) FLAMERETARDANT CRG1SANJ4R7RT
R7519-7522 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) FLAMERETARDANT CRG2SANJR47RT
z
R7526 252310006520S PTC THEMISTORS, CHIP(95'C)
CRTPRF18BD471QB5RB
R7532 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R7703 nsp RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R7704 nsp RES,M-OXIDEFILM(1W/100ohm) CRG1SANJ101RT
R7715-7720 nsp RES,M-OXIDEFILM(1W/2.2Kohm) CRG1SANJ222RT
R7721-7725 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
VR710 963161012400S RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T
VR720 963161012400S RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T
VR730 963161012400S RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T
VR740 963161012400S RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T
VR750 963161012400S RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T
OTHERS PARTS GROUP
BK701 nsp PCB BRACKET
CMD1A569
BN701 nsp
WIRE ASS'Y Locking (YH)
(13P,2MM,100MM,#26)
CWB1B013100HC
BN702 nsp
WIRE ASS'Y Locking (YH)
(7P,2MM,180MM,#26)
CWB1B007180HC
BN705 nsp
WIRE ASS'Y Locking (YH)
(3P,2MM,300MM,#26,105)
CWB4B003300HC
BN706 nsp WIRE ASS'Y (1P, 180MM,RED,#18,CKM-T) CWE8212180TT
BN707 nsp WIRE ASS'Y (1P, 180MM,BLK, #18,CKM-T) CWE8202180TT

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
