Denon AVR-1612 Service Manual

102
INPUT PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC401 90M-HC109700R IC NJM2595MTE1
CVINJM2595MTE1
IC404 943235003810S IC R2A15218FP CVIR2A15218FP
IC406 00MHC1010455Y IC MM1511XNRE HVIMM1511XNRE
Q4004 943214500030S T.R , MUTE CVTINC2001AC1 *
Q4005 943216500050S T.R,RT1N441C(47K-47K)
CVTRT1N441C
*
Q4007 943215500030S T.R,RT1P441C(47K-47K)
CVTRT1P441C
*
Q4009 943216500050S T.R,RT1N441C(47K-47K)
CVTRT1N441C *
Q4010 943215500030S T.R,RT1P441C(47K-47K)
CVTRT1P441C *
Q4012 943215500030S T.R,RT1P441C(47K-47K)
CVTRT1P441C *
Q4013 943214500030S T.R , MUTE
CVTINC2001AC1 *
Q4015 943215500030S T.R,RT1P441C(47K-47K)
CVTRT1P441C
*
Q4016 943214500030S T.R , MUTE
CVTINC2001AC1 *
D4002 00D2760760905 DIODE , ZENER 3.6V
CVDZJ3.6BT
D4003 943209001080S DIODE 1SS355T CVD1SS355T
D4004 00D9430196306 DIODE ZJ7.5B CVDZJ7.5BT
D4005 943209001080S DIODE 1SS355T CVD1SS355T
D4006 00D9430196306 DIODE ZJ7.5B CVDZJ7.5BT
D4007 943209001080S DIODE 1SS355T CVD1SS355T
RESISTORS GROUP
R4078,4079 nsp METAL OXID EFILM RES(68OHM 1W)
CRG1SANJ680RT
CAPACITORS GROUP
C4002 nsp CHIP CAP 8200UF 50V
CCUS1H822KC
C4004 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C4005 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C4006,4007 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C4008,4009 nsp CHIP CAP 220PF 50V CCUS1H221JA
C4010,4011 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C4012 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C4013 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C4014,4015 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C4016 nsp CHIP CAP 220PF 50V CCUS1H221JA
C4017,4018 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C4020 00D9630324607 CAP , ELECT(10V/47uF) CCEA1AH470T
C4022 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C4024 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4026 00D9430062101 ELECT CAP 100UF 16V E3 CCEA1CH101T
C4026 943134500060S ELECT CAP 100UF 50V E2,EA,E1C CCEA1HH101T
C4027 943134010470S ELECT CAP 0.1UF 50V CCEA1HH0R1T
C4029 nsp CHIP CAP 3900PF 50V K CCUS1H392KC
C4031,4032 nsp CHIP CAP 220PF 50V CCUS1H221JA
C4037 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C4039 nsp CHIP CAP 3900PF 50V K CCUS1H392KC
C4041 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C4044 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C4045 nsp CHIP CAP 8200UF 50V CCUS1H822KC
C4046 nsp CHIP CAP 22PF 50V CCUS1H220JA
C4047 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C4052 00D9630324607 CAP , ELECT(10V/47uF) CCEA1AH470T
C4055 943134010590S ELECT CAP 22UF 50V CCEA1HH220T
C4056 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4057 00D9630324607 CAP , ELECT(10V/47uF) CCEA1AH470T
C4058 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4059 00D9630324607 CAP , ELECT(10V/47uF) CCEA1AH470T
C4060, 4061 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4062, 4063 00D9430175108 ELECT CAP 10UF 50V E3 CCEA1HH100T
C4062, 4063 943134500070S ELECT CAP 10UF 100V E2,EA,E1C CCEA2AH100TS *
C4064 943134010590S ELECT CAP 22UF 50V
CCEA1HH220T
C4065 943134010470S ELECT CAP 0.1UF 50V CCEA1HH0R1T

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
