Denon AVR-1612 Service Manual

101
Ref. No. Part No. Part Name Remarks Q'ty New
L2527 nsp
RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T
L2529-2534 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T
L2535,2536 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T
L2539,2540 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T
L2543-2568 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T
L3400,3401 nsp FERRITE , CHIP BEAD(220ohm, 2012) CLZ9R006Z
L3402 nsp FERRITE , CHIP BEAD(220ohm, 2012) CLZ9R006Z
L3403,3404 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T
L3405 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T
X1001 943141010350S
CRYSTAL, 28.636MHz, HC-49/SMD, 33pF,
30PPM
COX28636E330S
X2001 00D3991038900 CRYSTAL, 12MHZ(SMD, FCX-03) COX12000I100SR
X3401 943141100030S CRYSTAL, 12MHZ(SMD, FCX-03, 15ppm) COX12000I100PPM15SR *
X4001 141810046500S
CRYSTAL, 24.576MHZ(SMD, FCX-04) COX24576I100SR
X4002
943141100020S
CRYSTAL , 21.875MHZ(SMD , FCX-04) COX21875I070SR
*

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
