Denon AVR-1612 Service Manual

100
Ref. No. Part No. Part Name Remarks Q'ty New
C4408 943134500040S
CAP, CHIP ELECT(16V/100uF) HCEC1CRV2101T *
C4411,4412 nsp
CHIP CAP 3900PF 50V K CCUS1H392KC
C4423,4424 nsp CAP, CHIP(1608, 50V/680pF) CCUS1H681JA
C4425,4426 nsp CAP, CHIP(1608, 50V/680pF) CCUS1H681JA
C4429,4430 943134500040S CAP, CHIP ELECT(16V/100uF) HCEC1CRV2101T *
C4431,4432 nsp
CHIP CAP 3900PF 50V K CCUS1H392KC
C4443,4444 nsp CAP, CHIP(1608, 50V/680pF) CCUS1H681JA
C4445,4446 nsp CAP, CHIP(1608, 50V/680pF) CCUS1H681JA
C4451,4452 nsp CHIP CAP 3900PF 50V K CCUS1H392KC
C4463,4464 nsp CAP, CHIP(1608, 50V/470pF) CCUS1H471JA
C4465,4466 nsp CAP, CHIP(1608, 50V/470pF) CCUS1H471JA
C4471,4472 nsp CHIP CAP 3900PF 50V K CCUS1H392KC
C4483,4484 nsp CAP, CHIP(1608, 50V/680pF) CCUS1H681JA
C4485,4486 nsp CAP, CHIP(1608, 50V/680pF) CCUS1H681JA
C4491 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4492 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4493,4494 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4495 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4496-4498 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4499 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4505,4506 nsp CHIP CAP 4700PF 50V CCUS1H472KC
C4507,4508 943134500050S CAP, CHIP ELECT(16V/10uF) HCEC1CRV2100T *
C4511,4512 nsp
CHIP CAP 1UF 10V CCUS1A105KC
C4514 nsp CAP, CHIP(2012, 10V/4.7uF) CCUC1A475ZF
C4516 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C4581-4584 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4585-4587 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4588,4589 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4590 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4591 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4592 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4593 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4609-4611 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C4612,4613 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
OTHERS PARTS GROUP
BK102-104 nsp
BRACKET , PCB CMD1A569
CN101 nsp WAFER , CARD CABLE (SMD) CJP07GA193ZY
CN151 nsp LOCK-WAFER/STRAIGHT/2.5mm CJP05GI237ZW
CN202 nsp WAFER , CARD CABLE (SMD) CJP07GA193ZY
CN203 nsp WAFER , 4PIN ANGLE CARD CABLE 1MM CJP04GB113ZY
CN251 nsp WAFER,FPC 1.25mm,stright CJP27GA285ZN
CN252 nsp LOCK-WAFER/STRAIGHT/2mm CJP07GI236ZW
CN253 nsp PIN SOCKET (13P,1.25mm,ANGLE, B-TO-B) CJP13HJ282Z
CN254 nsp PIN SOCKET (21P,1.25mm,ANGLE, B-TO-B) CJP21HJ282Z
CN341 nsp WAFER , SMD (2MM PITCH) CJP05GA208ZY
CN403 nsp PIN SOCKET (23P,1.25mm,ANGLE, B-TO-B) CJP23HJ282Z
ET15,16 nsp PALTE , EARTH HJT1A025
JK101-105 943643100040S JACK, HDMI(KSI-TWI, W/ FLANGE) CJJ9H014Z
JK201 943643010220S JACK, 3.5PI HORIZONTAL W/O RING CJJ2E033Z
JK401 943643100170S JACK , BOARD CJJ4M043Y
JK402 262010004005S MODULE , OPTICAL (RX,3.3V) HJSTORX147L
L1001-1008 nsp FERRITE , CHIP BEAD(60ohm, 1608) CLZ9R005Z
L1009 nsp FERRITE , CHIP BEAD(60ohm, 1608) CLZ9R005Z
L1501 nsp FERRITE , CHIP BEAD(60ohm, 1608) CLZ9R005Z
L1503,1504 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T
L1509 nsp FERRITE , CHIP BEAD(60ohm, 1608) CLZ9R005Z
L1511,1512 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T
L1513 nsp FERRITE , CHIP BEAD(60ohm, 1608) CLZ9R005Z
L1514-1518 nsp FERRITE , CHIP BEAD(60ohm, 1608) CLZ9R005Z
L1520,1521 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T
L2501-2525 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
