Denon AVR-1612 Service Manual

99
Ref. No. Part No. Part Name Remarks Q'ty New
C3430,3431 nsp
CHIP CAP 0.1UF 16V CCUI1C104KC
C3432,3433 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3434 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C3435 nsp CAP, CHIP(1005, 50V/390pF) CCUI1H391JA
C3436 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3437 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3438 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3439 nsp CAP, CHIP(1005, 50V/1200pF) CCUI1H122KC
C3440 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3441,3442 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3443 nsp
CAP, CHIP(1608,6.3V/4.7uF) (MURATA
GRM18)
CCUS0J475KC
C3447-3449 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3453,3454 nsp CAP, CHIP(1608, 50V/9pF) CCUS1H090DA
C3455 nsp CHIP CAP 1UF 10V CCUS1A105KC
C3456,3457 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3458 nsp CHIP CAP 1UF 10V CCUS1A105KC
C3459-3462 nsp
CAP, CHIP(1608,6.3V/4.7uF) (MURATA
GRM18)
CCUS0J475KC
C3463,3464 nsp CAP, CHIP(1608, 50V/2200pF) CCUS1H222KC
C3465 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C3468,3469 nsp CAP, CHIP(1005, 50V/100pF) CCUI1H101JA
C4002 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C4003 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4004 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4005-4009 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4010 nsp CHIP CAP 0.022UF 50VK CCUS1H223KC
C4011,4012 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4013 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4015 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C4016,4017 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4018,4019 nsp CAP, CHIP(1005, 50V/10pF) CCUI1H100JA
C4020 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4021 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4022-4030 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4031,4032 nsp CAP, CHIP(1608, 50V/10pF) CCUS1H100JA
C4033-4035 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4036 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4037 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4038-4043 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4044-4046 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4047,4048 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4049-4056 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4057 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4058-4065 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4066 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4067 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4068 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4069-4074 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4075,4076 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4077-4084 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4085 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4086 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4087 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4088,4089 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4090-4092 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4093,4094 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4095-4104 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4105,4106 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4107 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4108 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4109 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4110-4115 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C4116 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4402 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C4405 nsp CAP, CHIP(2012, 10V/4.7uF) CCUC1A475ZF
C4407 nsp CAP, CHIP(2012, 10V/4.7uF) CCUC1A475ZF

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
