Denon AVR-1612 Service Manual

96
DIGITAL PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 943236012460S
IC HDMITransceiver(LQFP-144P) CVIADV7623BSTZ
IC102 943248100080S I.C, FLASH MEMORY(AVR1612_E2_OSD) E2,EA CVIANAM1568AV *
IC102 943248100060S
I.C, FLASH MEMORY(AVR1612_E3_OSD) E3 CVIANAM1569AV *
IC102 943248100090S
I.C, FLASH MEMORY(AVR1612_E1C_OSD) E1C CVIANAM1605AV *
IC151 nsp
IC EX3AV CVIEX3AV
IC153 nsp IC EX3AV CVIEX3AV
IC154 231310009508S I.C , REGULATOR (3.3V) CVIPQ033DNA1ZPH
IC155 234810015507S I.C, VOLTAGE DETECTOR(4.8V) CVIBU4248F-TR
IC156 nsp IC EX3AV CVIEX3AV
IC157 231810090509S I.C , REGULATOR (1.8V) CVIPQ018ENA1ZPH
IC201 943243100040S I,C , U-COM(AVR1612_E2) E2,EA CVIANAM1608AV *
IC201 943243012660S
I,C , U-COM(AVR1612_E3) E3 CVIANAM1560AV
*
IC201 943243100050S
I,C , U-COM(AVR1612_E1C) E1C CVIANAM1609AV *
IC201 943243100060S
I,C , U-COM(AVR1622_E1C) 1622E1C CVIANAM1610AV *
IC202 246810026500S
I.C EEPROM(256K, 32-kword x 8 bit) CVIR1EX24256ASAS0A
IC251 00D2623410907 IC TC74VHCT08AFT HVITC74VHCT08FT
IC252 00D2623444902 IC TC74VHC08FT CVITC74VHC08FT
IC253 963239002150S I.C , OCTAL BUFFER/DRIVER CVISN74LVC244APWR
IC301 963239008830S 32BIT RISC CPU CVITCC860000XEARUG
IC340 943248012670S I.C, FLASH MEMORY(AVR1612_USB) CVIANAM1561AV *
IC341 963239010380S
I.C, 64M SDRAM CVIIS42S16400F-6TL
IC342 nsp
I.C , IPOD AUTHENTICATION CHIP FROM
MARANTZ
CVI236710076509S-DM
IC344 236810070500S I.C, STEREO DAC (TSSOP16) CVIAK4424ET
IC345 943652500030S POLY SWITCH (1.6A, 8V) CBA5H1600PSUYT *
IC401 00D2623077900
I.C , HEX INVERTER HVITC74VHCU04FT
IC402 236810062608S I.C , DIR CVILC89058W-E
IC403 943236100020S I.C, FLASH MEMORY(AVR1612_PLD) CVIANAM1570AV *
IC404
nsp I.C , DSP(LQFP-176P/350M) CVIADSP21487KSWZ-3B
IC405 943246012690S I.C , 64M SDRAM CVIW9864G6JH-6
IC406 943248012680S I.C, FLASH MEMORY(AVR1612_DSP) CVIANAM1562AV *
IC441 236810073509S
I.C , DAC(8CH 192kHz 24-Bit) CVIAK4358VQ
IC442,443 00D2631289900 IC AZ4580MTR-E1 CVIAZ4580MTR-E1
IC445 00D2631289900 IC AZ4580MTR-E1 CVIAZ4580MTR-E1
IC447 00D2631289900 IC AZ4580MTR-E1 CVIAZ4580MTR-E1
IC451 236810086505S I.C , ADC(96kHz 24-Bit) CVIAK5358BET
Q1001 943215500020S TR RT1P141C CVTRT1P141C
Q1002 943216500040S TR RT1N241C CVTRT1N241C
Q1003 943215500020S TR RT1P141C CVTRT1P141C
Q1004 943216500040S TR RT1N241C CVTRT1N241C
Q1005 943215500020S TR RT1P141C CVTRT1P141C
Q1006 943216500040S TR RT1N241C CVTRT1N241C
Q1007 943215500020S TR RT1P141C CVTRT1P141C
Q1008 943216500040S TR RT1N241C CVTRT1N241C
Q1009 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C *
Q1501 943216500050S
T.R,RT1N441C(47K-47K) CVTRT1N441C *
Q1502 943229500020S
MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111
*
Q1508 943216500050S
T.R,RT1N441C(47K-47K) CVTRT1N441C *
Q1510 943229500020S
MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111
Q1512 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C *
Q1514 943229500020S
MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111
*
Q1515 00D2710326904
T.R,2SA1954 CVT2SA1954
Q1516 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C *
Q1517 943216500020S
TR RT1N141C CVTRT1N141C
Q1518 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 *
Q1519 00D2710326904
T.R,2SA1954 CVT2SA1954
Q1520 943216500020S TR RT1N141C CVTRT1N141C
Q1521 00D2710326904 T.R,2SA1954 CVT2SA1954
Q1522 943216500020S TR RT1N141C CVTRT1N141C
Q1523 943214500020S TR 2SC3052 CVT2SC3052
Q2006,2007 943214500020S TR 2SC3052 CVT2SC3052
Q2008 943214500030S T.R , MUTE CVTINC2001AC1
*
Q2009,2010 943216500020S
TR RT1N141C CVTRT1N141C
NOTE :
When update Firmware,
please conrm a last
version in SDI.
Use the service board
after updating it.

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
