Denon AVR-1612 Service Manual

97
Ref. No. Part No. Part Name Remarks Q'ty New
Q2012 943216500020S
TR RT1N141C CVTRT1N141C
Q2013 943216500020S TR RT1N141C CVTRT1N141C
Q2504 943214500020S TR 2SC3052 CVT2SC3052
Q2505,2506 943216500020S TR RT1N141C CVTRT1N141C
Q2507 943214500020S TR 2SC3052 CVT2SC3052
Q2508,2509 943216500020S TR RT1N141C CVTRT1N141C
Q2513 943214500020S TR 2SC3052 CVT2SC3052
Q3401,3402 943216500020S TR RT1N141C CVTRT1N141C
Q3403 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 *
Q3404 943215500020S
TR RT1P141C CVTRT1P141C
Q4001 943216500020S TR RT1N141C CVTRT1N141C
Q4002 943215500020S TR RT1P141C CVTRT1P141C
D1501 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP
D2006 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP
D2501 943209001080S DIODE 1SS355T CVD1SS355T
RESISTORS GROUP
R1038 nsp
RES,CHIP(1608/1%/1.6Kohm) CRJ10DF1601T
R1039 nsp RES,CHIP(1608/1%/2Kohm) CRJ10DF2001T
R1504 nsp RES, CHIP(1608/1%/47Kohm) CRJ10DF4702T
R1506 nsp RES, CHIP(1608/1%/150Kohm) CRJ10DF1503T
R1516 nsp RES, CHIP(1608/1%/470Kohm) CRJ10DF4703T
R1518 nsp RES, CHIP(1608/1%/150Kohm) CRJ10DF1503T
R1546 nsp RES, CHIP(1608/1%/120Kohm) CRJ10DF1203T
R1548 nsp RES, CHIP(1608/1%/150Kohm) CRJ10DF1503T
R2031 nsp RES,CHIP(0OHM,5%,1608) E2,EA CRJ10DJ0R0T
R2031 nsp CHIP RES,10K OHM 1/10W J E1C CRJ10DJ103T
R2031 nsp RES , CHIP(3.3K OHM , 5% , 1608) 1622E1C CRJ10DJ332T
R2032 nsp RES,CHIP(0OHM,5%,1608) E3 CRJ10DJ0R0T
R2032 nsp CHIP RES,10K OHM 1/10W J E1C CRJ10DJ103T
R2032 nsp RES , CHIP(18K OHM , 5% , 1608) 1622E1C CRJ10DJ183T
CAPACITORS GROUP
C1001-1004 nsp
CHIP CAP 0.1UF 16V CCUI1C104KC
C1005 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1006 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1007 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1008-1024 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1025 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1026 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1027 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1028 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1029 nsp CHIP CAP 1UF 10V CCUS1A105KC
C1030 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1031 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1033-1035 nsp CHIP CAP 1UF 10V CCUS1A105KC
C1036 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1037-1040 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1041 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1042 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1043 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1044 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1047-1050 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1051 nsp CAP, CHIP(1005, 50V/1000pF) CCUI1H102KC
C1052 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1053,1054 nsp CHIP CAP 47PF 50V CCUS1H470JA
C1063 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1067 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1501 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C1502 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C1503 nsp CAP, CHIP(1005, 25V/0.01uF) CCUI1E103KC
C1506 nsp CAP, CHIP(1005, 50V/15pF) CCUI1H150JA
C1509 nsp CAP,CHIP(2012,10V/22uF) CCUC1A226KC

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
