Denon AVR-1612 Service Manual

15
1. µcom/DSP Version display mode
1.1. Operation specications
µcom/DSP version display mode:
When the set is started up in this mode, the version information is displayed.
Starting up:
Press the "ON/STANDBY" button to turn on the power while pressing the "STATUS" and "DIMMER" buttons.
Now, press the "STATUS" button to the display the 2nd item information on the FL Display.
b
When the version is displayed on the FL Display, the version list is also displayed on the OSD.
1.2. Display Order
Error information(Refer to 1.3. Error display) →
q
Model destination information →
w
Main µ-com Version
→
e
Main FBL →
r
DSP Version →
t
Audio PLD Version →
y
OSD Version →
u
USB Version
→
i
iPod Version (Connected only)
q
Model destination information :
FLD
A V R 1 6 1 2 E 3
FLD
A V R 1 6 1 2 E 2 / E A
FLD
A V R 1 6 1 2 E 1 C
FLD
A V R 1 6 2 2 E 1 C
w
Main µ-com Version :
FLD
M a i n : * * * * # # # #
(* : Main version, #: Sub version)
e
Main FBL :
FLD
M a i n F B L : * * . * *
r
DSP Version :
FLD
D S P : * * . * *
t
Audio PLD Version :
FLD
A u d i o P L D : * * . * *
y
OSD Version :
FLD
O S D : @ @ $ x * * * *
(@: Model code, $: Brand code, x: Region code, *: version)
u
USB Version :
FLD
U S B : * * . * *
i
iPod Version :
FLD
* i P o d D o c k : * * . * *
(ASD-1R/11R)
FLD
* D o c k : * * * * * * * * *
(ASD-3/51)
