Denon AVR-1612 Service Manual

4. DIAGNOSTIC MODE (Video/Audio (signal) path conrmation mode)
This mode is used for conrming the Video and Audio (signal) paths. (Troubleshooting)
Conrming the operation of unit can be easily done after repair.
Backup data will not be lost.
4.1. Starting diagnostic mode
Press the "iPod system
2
" and "STATUS" button while simultaneously pressing those two buttons of this unit.
Q1, Q2 and Q3 are lit in FL display.
4.2. Canceling diagnostic mode
Turn off the power by pressing the ON/Standby button.
4.3. Operation
When you perform remote operation in accordance with the instructions in "Details of how to operate remote controller" *a) in the table below using the remote control unit (RC-1156 or RC-1157).
You will nd using another remote control unit with the macro functions very useful. To use the macro functions, program a macro function to output a remote control code in accordance with the steps in *b) in the table below.
4.4. Video system conrmation items
g.XX : Refer to the block diagram of the g.XXth.
Conrmation item Setting and display Details of how to operate remote controller *a)
Output sequence of remote control codes
※
It is useful to form a macro program. *b)
Contents of conrmation Remarks
1
Analog Video (signal) Path Display:
V 0 1 D V D
1.Press [ZONE SELECT], Select "MAIN"
2.Press [1/./]
q
KEY 1/CODE1 (Main Zone)
Initialization
·Input : CVBS / Output : CVBS
·Input : S / Output : CVBS
3.Press [ZONE SELECT], Select "MAIN"
4.Press [DVD]
w
DVD (Main Zone)
2
HDMI (signal) Path Display:
V 0 1 D V D
1.Press [ZONE SELECT], Select "MAIN"
2.Press [1/./]
q
KEY 1/CODE1 (Main Zone)
Initialization
·Input HDMI / Output : HDMI
(
b
As the input source, you can switch from DVD to other ones.)
3.Press [DVD]
w
DVD (Main Zone)
3
OSD FUNCTION Menu : ON
Display:
V 0 2 D V D
1.Press [ZONE SELECT], Select "MAIN"
2.Press [2/ABC]
q
KEY 2/ABC (Main Zone)
Initialization
·OSD Display / Output : HDMI
(
b
As the input source, you can switch from DVD to other ones.)
3.Press [ZONE SELECT], Select "MAIN"
4.Press [DVD]
w
DVD (Main Zone)
5.Press [AMP]
6.Press [MENU]
e
GUI MENU (Main Zone)
4
CEC FUNCTION
(Control Monitor : HDMI Monitor)
HDMI Control : ON
Display:
V 0 3 D V D
1.Press [ZONE SELECT], Select "MAIN"
2.Press [3/DEF]
q
KEY 3/DEF (Main Zone)
Initialization & CEC Control ON
· When the power supply of a TV is put in the standby mode, make sure
that the power supply of this unit is also put in the standby mode.
(
b
As the input source, you can switch from DVD to other ones.)
3.Press [DVD]
w
DVD (Main Zone)
5
HDMI Audio (signal) Path
(Audio : AMP)
Audio : AMP(When checking the audio output
from AMP)
Display:
V 0 5 D V D
1.Press [ZONE SELECT], Select "MAIN"
2.Press [5/JKL]
q
KEY 5/JKL (Main Zone)
Initialization & Select Audio AMP
·Input : HDMI (Signal of PCM, DolbyDigital or DTS) / Output : Speakers
·Input : HDMI (Signal of HD Audio) / Output : Speakers
(
b
As the input source, you can switch from DVD to other ones.)
3.Press [DVD]
w
DVD (Main Zone)
6
HDMI Audio (signal) Path
(Audio : TV)
Audio : TV(When checking the audio output
from TV)
Display:
V 0 6 D V D
1.Press [ZONE SELECT], Select "MAIN"
2.Press [6/MNO]
q
KEY 6/MNO (Main Zone)
Initialization & Audio Select TV
· Input : HDMI (Signal of PCM or DolbyDigital or DTS) / Output : HDMI
(Audio output from connected TV)
(
b
As the input source, you can switch from DVD to other ones.)
3.Press [DVD]
w
DVD (Main Zone)
g.1
g.2
g.3
g.4
g.5
g.6
21

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
