Denon AVR-1612 Service Manual

4.5. Audio system conrmation items
g.XX : Refer to the block diagram of the g.XXth.
Conrmation item Setting and display Details of how to operate remote controller
Output sequence of remote control codes
b
It is useful to form a macro program.
Contents of conrmation Remarks
1
Analog (signal) Path Input Mode : Fixed ANALOG
SURROUND mode : DIRECT
Amp assign : NORMAL
Display:
A 0 1 D V D
1.Press [ZONE SELECT], Select "MAIN"
2.Press [7/PQRS]
q
KEY 7/PQRS (Main Zone)
Initialization & Amp assign NORMAL& Input Mode
Fixed ANALOG & SURROUND mode DIRECT
·Input : Analog / Output : Speakers (Front L/R)
(
b
As the input source, you can switch from DVD to other ones.)
3.Press [DVD]
w
DVD (Main Zone)
2
DIGITAL (signal) Path
(MAIN)
Input Mode : Fixed DIGITAL
Amp assign : NORMAL
Display:
A 0 2 D V D
1.Press [ZONE SELECT], Select "MAIN"
2.Press [8/TUV]
q
KEY 8/TUV (Main Zone)
Initialization & Amp assign NORMAL& Input Mode
Fixed DIGITAL
·Input : Digital / Output : Speakers (Front L/R)
(
b
As the input source, you can switch from DVD to other ones.)
3.Press [DVD]
w
DVD (Main Zone)
3
HDMI (signal) Path Input Mode : Fixed HDMI
Amp assign : NORMAL
Display:
A 0 5 D V D
1.Press [ZONE SELECT], Select "MAIN"
2.Press [MOVIE]
q
MOVIE Select
Initialization &Amp assign NORMAL & Input Mode
Fixed HDMI
·Input : HDMI / Output : Speakers (Front L/R)
(
b
As the input source, you can switch from DVD to other ones.)
3.Press [DVD]
w
DVD (Main Zone)
4
A/D (signal) Path
(Main Zone)
Amp assign : NORMAL
SURROUND mode : Multi ch STEREO
Vol -20dB
Speaker Cong : SSSSY
(Front/Center/Surround/SourroundBack : Small, SW : Yes)
Display:
A 0 6 D V D
1.Press [ZONE SELECT], Select "MAIN"
2.Press [MUSIC]
q
MUSIC
Initialization &Amp assign NORMAL &
SURROUND mode : Multi ch STEREO & Volume
-20dB
·Input : Analog / Output : Speakers (Front L/R)
·Input : Analog / Output : SW(20Hz)
(
b
As the input source, you can switch from DVD to other ones.)
3.Press [DVD]
w
DVD (Main Zone)
g.7
g.8
g.9
g.10
22

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
