Denon AVR-1612 Service Manual

107
Ref. No. Part No. Part Name Remarks Q'ty New
BN7702,7703 nsp WIREASS'Y (1P, 40MM)
CWE7202040TT
BN7705 nsp WIREASS'Y (1P, 40MM) CWE7202040TT
BN7707 nsp WIREASS'Y (1P, 40MM) CWE7202040TT
CN703 nsp WAFER(3PIN 3.96MM) CJP03GA148ZW
CN710 nsp WAFER STRAIGHT 2PIN CJP02GA01ZY
CN720 nsp WAFER STRAIGHT 2PIN CJP02GA01ZY
CN730 nsp WAFER STRAIGHT 2PIN CJP02GA01ZY
CN740 nsp WAFER STRAIGHT 2PIN CJP02GA01ZY
CN750 nsp WAFER STRAIGHT 2PIN CJP02GA01ZY
ET701 nsp EARTH PALTE HJT1A025
ET702 nsp WIRE ASS'Y (1P, 80MM,BLK,#22) CWE5202080A
JK701 943646010250S JACK NOSPCC4PRR/BB CJJ5P011U
JK702 943646010240S JACK NOSPCC6PRRR/BBB CJJ5R008U
L7101 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
L7201 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
L7301 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
L7401 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
L7501 943115010260S SPEAKER COIL (0.5UH) CLEY0R5KAK
RY760 943682000810S RELAY 12V 2C2P CSL4A016ZU
RY762-764
682010023006S
RELAY 12V 2C1P CSL3A021ZU

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
