Denon AVR-1612 Service Manual

109
Ref. No. Part No. Part Name Remarks Q'ty New
C9316 00D9430103905 ELECT CAP470UF 16V
CCEA1CH471T
C9317 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C9320 00MOA10801620 CAP , ELECT(16V/1000uF) CCEA1CH102E
C9321 00D9430103905 ELECT CAP470UF 16V CCEA1CH471T
C9324,9325 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C9328 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
OTHERS PARTS GROUP
BK901,902 nsp PCB BRACKET
CMD1A188
BK903 nsp BRACKET , PCB CMD1A629
BN903 nsp
WIRE ASS'Y Locking (YH)
(5P,2.5MM,350MM,#22,105)
CWB4D0053503D
CN254 nsp PIN HEADER (21P,1.25mm,STRAIGHT,B-TO-B) CJP21GI281Z
CN255 nsp PIN HEADER (13P,1.25mm,STRAIGHT,B-TO-B) CJP13GI281Z
CN256,257 nsp PIN HEADER (23P,1.25mm,STRAIGHT,B-TO-B) CJP23GI281Z
CN258 nsp PIN HEADER (13P,1.25mm,STRAIGHT,B-TO-B) CJP13GI281Z
CN259 nsp PIN HEADER (19P,1.25mm,STRAIGHT,B-TO-B) CJP19GI281Z
CN901 nsp WAFER 2PIN 2MM E3 CJP02KA060ZY
CN902 nsp WAFER 2PIN CJP02GA89ZY
CN931 nsp LOCK-WAFER/STRAIGHT/2.5mm CJP09GI237ZW
CN932 nsp WAFER STRAIGHT(7PIN 2.5MM) CJP07GA01ZY
z
CX901 943139500020S CAP , POLYPROPYLENE FILM
HCQF2E104KZE *
z
CY901,902 963134011730S CAP, CERAMIC(X1/Y1,470P,AC250V)
CCKDKX471KBM
ET31 nsp EARTH PALTE HJT1A025
z
F9001 963652010500S FUSE(S506 Series, 250V,1.6A) E2,EA,E1C CBA2C1600TLEC
z
F9001 963652010510S FUSE(S506 Series, 250V,2A) E3
CBA2C2000TLEC
z
F9002 963652010910S FUSE(S506 Series, 250V,3.15A) E2,EA,E1C CBA2C3150TLEC
z
F9002 963652010540S FUSE(S506 Series, 250V,5A) E3
CBA2C5000TLEC
z
F9301,9302 00D2061096006 FUSE(218 Series, 250V, 1.25A) KBA2C1250TLEY
z
F9303,9304 00D2061095049 FUSE(218 Series, 250V, 0.315A)
KBA2C0315TLEY
JK901 963641011240S RECEPTACLE, (10A/AC250V/AC-015-2P-PA66) E2,EA CJJ8A015ZM
z
LF902 963111010230S LINE FILTER(LF-4ZB-E273H,27uH) CLZ9Z126Z
z
RY901 963682010370S RELAY, POWER(DC5V, 1C1P)
CSL1C006ZE
z
T9001 963102010240S TRANS, SWITCHING(ST-4430A) CLT9Z067ZE
nsp FUSE HOLDER KJCFC5S
nsp
FUSE HOLDER
KJCFC5S

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
