Denon AVR-1612 Service Manual

130
Pin Pin Name Symbol I/O
Pull up/
down
LvCnv STBY
CEC
STBY
Function
114 P64/CS4#-B ADC RST O - - L L A/D converter control pin(AK5358B)
115 P63/CS3#-A/CS7#-A E SPI REQ I Pd - L L ETHERNET communication control pin(DM860)
116 P62/CS2#-A/CS6#-A E SPI CS 0 N3VPu - L L ETHERNET communication control pin(DM860)
117
P61/CS1#/CS2#-B/
CS5#-A/CS6#-B/CS7#-B
DAC MS O - - L L A/D converter control pin(AK4358VQ)
118
P60/CS0#/CS4#-A/
CS5#-B
DAC RST O - - L L A/D converter control pin(AK4358VQ)
119 PD3/D3 VEXP STB O - 3->5 L L VIDEO expander control pin(MC14094BD)
120 PD2/D2 VEXP OE O Pd 3->5 L L VIDEO expander control pin(MC14094BD)
121 PD1/D1 VEXP CLK/FL CLK O - 3->5/- L L VIDEO expander control (MC14094BD) & FL control pin
122 PD0/D0 VEXP DIN/FL DATA O - 3->5/- L L VIDEO expander control (MC14094BD) & FL control pin
123 P97/AN15 DA POWER O - - L L Digital power supply (DA3.3V & DA1.2V) control pin (ON:H)
124 P96/AN14 CEC POWER O - - L H
CEC power supply (CEC5V & CEC3.3V & CEC1.8V) control
pin for CEC STANDBY.
125 P95/AN13 DV POWER O - - L
b
Digital (VIDEO) power supply (DV5V & DV3.3V) control pin.
*CEC STANDBY:MODE1=H, MODE2=L
126 P94/AN12 DV POWER2 0 - - L
b
Digital (VIDEO) power supply (DV1.8V) control pin. *CEC
STANDBY:MODE1=H, MODE2=L
127
P93/AN11 MAIN POWER O - - L L MAIN POWER control pin
128 P92/AN10 CPU POWER O - - L L
MAIN CPU POWER pin (POWER ON: H CEC ON =
STANDBY: H)
129 P91/AN9 MODEL I - - I I MODEL switch input pin (No assign)
130 VSS VSS - - - - - GND
131 P90/AN8 MODE I - - I I Destination detection pin
132 VCC VCC - - - - - +3.3V
133 P47/IRQ15-B/AN7 THERMAL B/DC DET/ASO I - - I I
ASO PROTECT / DC PROTECT / HEAT PROTECT-B
detection pin
134 P46/IRQ14-B/AN6 H/P DET / MIC DET/THERMAL A I - - I I
MIC detectionion / Headphone detectionion / HEAT
PROTECT-A detection pin
135 P45/IRQ13-B/AN5 KEY3 I SW3VPu - I I Button input 3
136 P44/IRQ12-B/AN4 KEY2 I SW3VPu - I I Button input 2
137 P43/IRQ11-B/AN3 KEY1 I SW3VPu - I I Button input 1
138 P42/IRQ10-B/AN2
RDS DATA(EU)/NC(KST-MW
MODEL)
I/I - 5->3 I I NC
139 P41/IRQ9-B/AN1
RDS CLK(EU)/NC(KST-MW
MODEL)
I/I - 5->3 I I NC
140 AVSS AVSS - - - - - GND
141 P40/IRQ8-B/AN0 CEC_IN I
SW3VPu - I I CEC-D signal input pin
142 VREF VREF - - - - - Reference voltage (+3.3V) input pin for A/D port
143 AVCC AVCC - - - - - +3.3V
144
P05/IRQ13-A/TMO3/
RxD4/TCK
NC I M3VPu - I I NC

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
