Denon AVR-1612 Service Manual

53
YES
YES
YES
YES
Check operation of each device.
(AMP source : BD / Video input of player : 480P / Connect the TV.)
Check operation of IC101(ADV7623)
(20) Check Xtal oscillator.
Is oscillation of X1001(28.6363MHz) transmitted?
(21) Check RESET.
Is RESET waveform conrmed in TP[RESET B], when power is
turned on? (If not reference waveform, proceed to "NO".)
(22) Check control signal(I2C).
Is waveform conrmed in TP[HSCL/HSDA], when power is turned
on? (If not reference waveform, proceed to "NO".)
The pattern and circuit from the HDMI connector (JK105) to the
IC(IC101) is defective, or HDMI output circuitry is defective (IC101
and surrounding circuitry).
(19) Check power supply.
Are 1.8V or 3.3V supplied to IC101(each power supply pin)?
Refer to [Detail C] of the substrate for test point.
The power supply circuitry is defective.
The X1001 or IC101 is defective.
The RESET circuitry or IC101 is defective.
The HSCL/HSDA line pattern is defective.
NO
NO
NO
NO

Denon AVR-1612 Specifications

General

Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	4
Composite video in	3
S-Video inputs quantity	1
Speakers connectivity type	-
Ethernet LAN	No
Radio Data System (RDS)	Yes
Preset stations quantity	56
Analog signal format system	NTSC, PAL
Display	LCD
HDMI version	1.4
Product color	Black
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-ES, DTS-HD
Apple docking compatibility	iPod
Graphical user interface (GUI) language	English, French, German
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	382 mm
Width	435 mm
Height	162 mm
Weight	9200 g
