Denon AVR-1612 - 4.3. Analog Audio

58
4.3. Analog audio
No sound is output
Is the voltage of ±12V supplied to
INPUT B'D CN406?
Is the audio signal transmitted to
INPUT B'D CN408?
Is the serial data for electronic volume
transmitted to INPUT B'D CN401?
Once more, check the connection of the connector.
When you can specify the troubled the channel and function, check the corresponding
signal route where it corresponds.
The power supply of ±12V is repaired.
The power amplier is repaired.
Is the connector correctly connected
with the DIGITAL B'D?
Connect the connectors properly.
The DIGITAL B'D is repaired.
YES
NO
YES
NO
NO
YES
YES
NO
