Denon AVR-X1000 User Manual

131
Appendix
TipsPlaybackConnections
Contents
Front panel Display Rear panel IndexRemote
Settings
TV Format
Set the video signal format to be output for the TV you are using.
2 Format
NTSC (Default) : Select NTSC output.
PAL : Select PAL output.
%
•“Format” can also be set by the following procedure. However, the menu
screen is not displayed.
1. Press and hold the main unit’s ZONE2 SOURCE and STATUS for at least 3
seconds.
“V.Format:<NTSC>” appears on the display.
2. Use the main unit’s TUNER PRESET CH +, – and set the video signal format.
3. Press the main unit’s STATUS to complete the setting.
NOTE
•When a format other than the video format of the connected TV is set, the
picture will not be displayed properly.

Denon AVR-X1000 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Pre-out channels	1 SW
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	5
Composite video in	2
Ethernet LAN (RJ-45) ports	1
Multichannel audio output type	RCA
Connectivity technology	Wired
AM antenna ports quantity	0
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPS
Wi-Fi	No
Supported radio bands	FM
Internet radio services supported	vTuner
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPhone
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	390 W
Cables included	AC

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	151 mm
Weight	8200 g
