Manual Setup
Perform when setting the speakers manually or when changing settings
made in Audyssey® Setup.
•If you change the speaker settings after performing Audyssey® Setup, it
will not be possible to select Audyssey MultEQ® XT, Audyssey Dynamic
EQ® and Audyssey Dynamic Volume® (vpage126, 127).
•“Manual Setup” can be used without changing the settings. Please set
if necessary.
Speaker Config.
Indicate speaker presence and select speaker size categories based on
bass reproduction capability.
2 Front
Set the front speaker size.
Large (Default) : Use a large speaker that can adequately play back very
low bass frequencies.
Small : Use a small speaker that has inadequate playback capacity for
very low bass frequencies. Note that for most multi-channel
speakers, this is the best choice.
%
•When “Subwoofer” is set to “No”, “Front” is automatically set to “Large”.
•When “Front” is set to “Small”, “Center” and “Surround“ can not be set to
“Large”.
2 Center
Set the presence and size of the center speaker.
Large : Use a large speaker that can adequately play back very low
bass frequencies.
Small (Default) : Use a small speaker that has inadequate playback
capacity for very low bass frequencies. Note that this
is almost always the best choice.
None : Select when a center speaker is not connected.
2 Subwoofer
Set the presence of a subwoofer.
Yes (Default) : Use a subwoofer.
No : Select when a subwoofer is not connected.
2 Surround
Set the presence and size of the surround speakers.
Large : Use a large speaker that can adequately play back very low
bass frequencies.
Small (Default) : Use a small speaker that has inadequate playback
capacity for very low bass frequencies. Note that this
is almost always the best choice.
None : Select when the surround speakers are not connected.
