Graphic EQ
Use the 9 band graphic equalizer to adjust the tone of each speaker.
%
•“Graphic EQ” can be set when “MultEQ® XT” (vpage128) setting is “Graphic
EQ”.
•Speakers for which “Graphic EQ” can be set dier according to the sound mode.
2 Speaker Selection
Select whether to adjust tones for individual speakers or for all
speakers.
All
Left/Right (Default)
Each
2 Adjust EQ
Adjust tonal balance for each frequency band. Adjust the speaker
selected in “Speaker Selection”.
q Select the speaker.
w Select the adjustment frequency band.
63Hz / 125Hz / 250Hz / 500Hz / 1kHz / 2kHz / 4kHz / 8kHz / 16kHz
e Adjust the level.
–20.0dB – +6.0dB (Default : 0.0dB)
2 Curve Copy
Copy “Audyssey Flat” curve from “MultEQ® XT” (vpage128).
%
•“Curve Copy” is displayed after Audyssey® Setup has been performed.
2 Set Defaults
The “Graphic EQ” settings are returned to the default settings.
