56
Appendix
TipsSettingsConnections
Contents
Front panel Display Rear panel IndexRemote
Playback
Radio Text
RT allows RDS stations to send text messages that appear on the display.
“Radio Text” appears on the display when radio text data is received.
1
Press OPTION when the input source is “TUNER”.
The option menu screen is displayed.
2
Use ui to select “Radio Text”, then press ENTER.
3
Use o p to select “On”, then press ENTER.
•While receiving an RDS broadcast station, the text data broadcast
from the station is displayed.
•If no text data is being broadcast, “NO TEXT DATA” is displayed.
Changing the tuning mode (Tune Mode)
You can change the mode for tuning into FM broadcasts. If you cannot
tune in automatically with “Auto” mode, then change the mode to
“Manual” and tune in manually.
1
Press OPTION when the input source is “TUNER”.
The option menu screen is displayed.
2
Use ui to select “Tune Mode”, then press ENTER.
3
Use o p to select tuning mode, then press ENTER.
Auto : Automatically search for and tune to a receivable radio
station.
Manual : Manually change the frequency one step at a time each
time the button is pressed.
Listening to preset stations
1
Use CH/PAGE df to select the desired preset channel.
%
•You can also select preset broadcast stations by pressing TUNER PRESET CH + or
TUNER PRESET CH – on the main unit.

Table of Contents

Other manuals for Denon AVR-X2000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X2000 and is the answer not in the manual?

Denon AVR-X2000 Specifications

General IconGeneral
Receiver type-
Frequency range10 - 100000 Hz
Output impedance16 Ω
Input sensitivity200 mV
Audio output channels7.1 channels
Signal-to-Noise Ratio (SNR)100 dB
Power output per channel (1KHz@6 Ohm)125 W
Power output per channel (20-20KHz@8 Ohm)95 W
HDMI in7
AC (power) inYes
Audio (L/R) in4
Composite video in2
Component video (YPbPr/YCbCr) in1
Connectivity technologyWired
Speakers connectivity typeBanana connector
Audio formats supportedAAC, FLAC, MP3, WAV, WMA
Image formats supportedJPG
Wi-FiNo
RDS featuresPTY, TP
FM band range87.5 - 108 MHz
Supported radio bandsFM
Internet radio services supportedSpotify, vTuner
Supported video modes1080i, 1080p, 480p, 576p, 720p
DisplayVFL
Color depth24 bit
Aspect ratio4:3, 16:9
Product colorBlack
Audio decodersDolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES, DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibilityNot supported
AC input voltage230 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.1 W
Power consumption (typical)500 W
Weight and Dimensions IconWeight and Dimensions
Depth330 mm
Width434 mm
Height167 mm
Weight9500 g
