Desoutter CVI3 Function User Manual

Appendix - Connections_02/2017- 36 -
APPENDIX - CONNECTIONS
1 - TOOL CONNECTOR
A
B
STA
STB
+15V
0V
Ground
Phase 1
Phase 2
Phase 3
(a)
(a)
(a)
(a)
(a)
(b) (b)
1mm² 1mm²
0.25mm²/120Ω
0.25mm²/120Ω
0.35mm²
0.35mm²
1mm² or 2.5mm²
1mm² or 2.5mm²
1mm² or 2.5mm²
1mm² or 2.5mm²
(a)
E
F
A
B
4
1
2
3
E
F
A
B
4
1
2
3
2 - RS232 - SubD 9pt
RX1
TX1
TX2
GND
1
2
3
4
RX2
RTS1
CTS1
5
6
7
8
+5V
9
9
8
7
6
5
4
3
2
1
RS1
RS2
Serial ports
Barcode reader
Legend
A Connector 12 pts Male
B Connector 12 pts Female
a Ground shielded cable
b WARNING : Shielded insulate
STA
Twisted pairs: 2x0.25 mm²
at 10 MHz 65 Ω
STB
Cable Color
STA Red
STB Red / Blue
+15V Black / Blue
0V Black
Ground Yellow / Green
Phase 1 Black
Phase 2 Brown
Phase 3 Blue
