Appendix - ePOD_02/2017- 42 -
APPENDIX - ePOD
The ePOD unlocks a specied level of functionality and acts as a back-up unit for the conguration of the CVI3 controllers.
It also increases the number of results, curves and logs in the controller.
There are different models of ePOD and specic ePOD designed for some specic protocols.
Model ePOD1 ePOD2 ePOD3 ePOD2C ePOD3C ePOD4C
Part number 6159360750 6159360760 6159360770 6159363110 6159363180 6159363120
Backup
Complete backup of the controller
system
included included included included included included
Results storage
Number of Pset results 10,000 20,000 20,000 20,000 20,000 20,000
Number of curves per tool 20 50 50 50 50 50
Number of Pset versions per Pset 10 20 20 20 20 20
Number of events in the event log 500 1,000 1,000 1,000 1,000 1,000
Basic functions
Number of steps per Pset:
- Tools with cable connection 15 15 40 15 15 40
- Wireless battery tools 10 10 10 10 10 10
CVILOGIX - included included included included included
Workgroup - - included - - included
Programming / Supervision / Controller backup
Results storage - included included included included included
Tightening units management (with CVI3 Vision controller only)
Maximum number of tightening units 2 2 2 3 3 4
Maximum number of wireless battery
tools
1 1 1 2 3 4
ePOD1
ePOD1 is a backup module for the controller result and conguration database.
- It can be used as real time backup module. In this case the ePOD1 must always be plugged to the controller.
- It also can be used as a manual backup that stores the conguration database, the results database and the rmware version of
the controller. ePOD1 gets a snapshot of the controller.
ePOD2
ePOD2 has all functionalities of ePOD1.
- ePOD2 activates CVILOGIX (Embedded PLC of CVI3 controllers).
ePOD3
ePOD3 has all functionalities of ePOD2.
- ePOD3 activates the workgroup conguration.
ePODxC
ePODxC has all functionalities of ePOD2 or ePOD3.
- It can be connected to CVI3 Vision controllers only.
