Desoutter CVI3 Function User Manual

Appendix - User info codes _02/2017- 28 -
Type of
code
Code
no.
Description Resolution procedure
Info 1 Tubenut open 1-Tubenut tool is detected as open
Info 2 Tool connected 1- The tool is connected and correctly recognized by the controller.
Info 3 No tool connected 1- Tool has been disconnected.
2- If the tool is not physically disconnected, check the tool cable.
Info 4 Span fail. 1- Span value from torque sensor is outside bounds.
2 -Try once again to start the tool with no mechanical constraints. If the
problem occurs again, contact your Desoutter representative for support
Info 5 Offset fail. 1- Offset value from torque sensor is outside bounds.
2- Try once again to start the tool with no mechanical constraints. If the
problem occurs again, contact your Desoutter representative for support.
Info 15 Tool lock on reject 1- The tool is locked forward after a NOK.
2- Unlock the tool in function of the "lock on reject option" selection i.e. by
reversing, loosening or input.
Info 16 Tool lock by OP 1- Tool has been locked by Open Protocol
2- Unlock the tool by sending an Enable tool message via Open Protocol
Info 17 Loosening prohibited 1- Loosening is prohibited
2- The loosening is disabled in the Assembly action
3- The batch count type OK + NOK is used
Info 21 Max retries reached 1- The number of retries max has been reached.
2- The tool is locked.
3- The running Assembly Process has to be aborted.
Info 22 Lock wait socket 1- The tool is locked. Put all sockets back and lift the correct socket(s)
combination.
Info 24 Loos. prohib. XML 1- Loosening is disabled by VWXML protocol
Info 25 Tight. prohib. XML 1- Tightening is prohibited by VWXML protocol
Info 26 Tool maint. alarm n1 1- Tool maintenance tightening counter has been reached
Info 27 Tool maint. alarm n2 1- Tool maintenance tightening counter has been reached
Info 38 Tool logs 1- Unexpected tool software exception
2- Log le has been generated by the tool
3-Contact your Desoutter representative for support
Info 40 Tool over speed 1- Motor speed exceeds 130% of its maximum value.
2- Check tool parameters.
3- Wrong motortune parameters. Contact your Desoutter representative
for support.
Info 42 Tool locked by GeoPos. 1- Tool has been locked by GeoPositioning
2- Unlock the tool by moving the tool in its dened area
Info 43 Tubenut maintenance 1- Tubenut settings need to be recongured. Please, use CVI Monitor
and refer to user's guide.
2- Contact your Desoutter representative for procedure
Info 44 GeoTracking/Positioning
learning mode ongoing
GeoTracking/Positioning learning mode
Info 46 Anormal battery current 1- Anormal battery current consumption, check your PSet settings.
2- This error can due to speed settings.
Info 50 Tool detection for pairing No procedure
Info 51 ePOD connected ePOD connected
Info 54 Pairing success No procedure
Info 55 eDOCK already present on
controller
No procedure
Info 56 ePOD disconnected ePOD disconnected
Info 57 Pairing error No procedure
Info 58 Tool locked by GeoTrack. 1- Tool has been locked by GeoTracking
2- Unlock the tool by moving the tool in its dened are
Info 59 New tool detected No procedure
Info 60 Tool synchro ongoing No procedure
APPENDIX - USER INFO CODES
Info For information only. No action is required.
Warning The tool is locked. Tap the message to unlock the tool.
Error The tool is locked. The issue has to be solved to unlock the tool and clear the error message.
