Desoutter CVI3 Function User Manual

Appendix - Connections_02/2017 - 41 -
8 - eBUS (for accessories)
B -
GND-EXT
AGND
2
3
B +
5
6
7
8
+24V-EXT
+24V
0V
9
1
4
9
8
7
6
5
4
3
2
1
9 - WORKGROUP
min. 5 mm
tool no. 2 tool no. 3 tool no. 4 tool no. 5
tool no. 1
Customer network
Workgroup network
For each secondary controller,
check that the quick stop is on
but inactive
Use «Eject» command before
disconnecting the ePOD.
ePOD3
SECONDARY CONTROLLERSPRIMARY CONTROLLER
