In the following table the main Features of the 52-1804 with a 52/DX control module are listed.
Feature
52-1804
support for redundant power supply
yes
number of supported faders
4
number of supported I/O boxes
3
number of audio, power & control ports (APC)
4
serial interface for external control
yes
TCP/IP interface for external control
yes
6.2 I/O modules and connections
Different I/O modules for audio and control inputs and outputs can be used for the 52/DX. Please find more information
about the I/O modules on the following pages.
It is also possible to connect two XS cores directly via Ethernet cable to exchange audio signals. Please find more
information about this in the DeviceLink section.
6.2.1 XS Multi-I/O Box
The 52-1330 XS Multi-I/O Box is an input/output module with common audio interfaces for the 52/DX mixing console.
In the following table you can find the type and number of interfaces, which are available on each XS Multi-I/O Box 52-
1330:
Interface type
Number
Specifications
Microphone/line inputs
2
-77…+18 dBu sensitivity
Headphone outputs
2
stereo
Analog line inputs
8
max. +24 dBu
Analog line outputs
8
max. +24 dBu
Digital inputs, AES3/EBU
3
sample rate converter, stereo
Digital inputs, S/PDIF
1
sample rate converter, stereo
Digital inputs, USB
2
sample rate converter, stereo
