10.6.1 Talkback
On the
Monitoring
page a talkback area with talkback specific settings is available. For each monitoring signal, you can
assign 2 talkback signals. These could be microphone inputs or other audio sources. You can switch on these talkback
signals by a logic source.
In the
Talkback 1/2
columns, in the
Source
boxes, you can insert an audio source which is activated by the logic
sources inserted in the
Condition
boxes.
To assign an audio source, as talkback into a monitoring signal, click the button, next to the
Source
box. The
Audio Sources
window opens. Select a audio source from the list and click assign.
To assign an logic source as talkback condition, click the button, next to the
Condition
box. The
Logic
Sources
window opens. Select a logic source from the list and click assign.
You can dim the monitor speaker signals, if a talk condition becomes true. To do this, select the corresponding
DIM
MON1/2 SPK
check box.
10.7 Buses
On the
Buses
page you can configure the settings for all buses that are available in the 52/DX system.
DXConfig Software - Buses
In the following tables all options on this page are explained.
