Talk 1 Source
Click the button, next to the
Talk 1 Source
box. The
Audio Sources
window opens. Select a audio source from the list and click assign.
When the
Talk 1 Condition
logic becomes true, the
Talk 1 Source
is
active on the corresponding bus.
Talk 2 Source
Click the button, next to the
Talk 2 Source
box. The
Audio Sources
window opens. Select a audio source from the list and click assign.
When the
Talk 2 Condition
logic becomes true, the
Talk 2 Source
is
active on the corresponding bus.
Talk Attenuation
When a Talk Source is active, the busses can be attenuated between
0 dB
and
Off
in steps of 1 dB. Use the
Talk Attenuation
selector to change the
attenuation value.
column
description
Bus name
Here you can find the name of the bus for which you configure the following settings.
Stereo
Select this check box, if the bus is stereo. Clear the check box to configure the bus as
mono.
Talk 1 Condition
Click the button, next to the
Talk 1 Condition
box. The
Logic
Sources
window opens. Select a logic source from the list and click assign.
When this logic source becomes true, the
Talk 1 Source
is active on the
corresponding bus.
Talk 2 Condition
Click the button, next to the
Talk 2 Condition
box. The
Logic
Sources
window opens. Select a logic source from the list and click assign.
When this logic source becomes true, the
Talk 2 Source
is active on the
corresponding bus.
Limiter
Select the
On
check box to activate the limiter for this bus.
Select a threshold value from the drop-down menu (-30 dB to 20 dB).
CF Source
Select from the drop down menu an audio source for your clean feed signal
Use Output select
Select this check box to enable source selection for the alternative clean feed signal.
Add to Selector List 1
Select this check box to add a bus to source list 1. This bus will be available for
monitoring in the
Selector
list, which is available in the
Selector
view of the
TFT/Touch Display.
